RM0366
To launch the communication, set the START bit of the I2C_CR2 register. The controller
then automatically sends a START condition followed by the target address, either
immediately if the BUSY flag is low, or t
state. The BUSY flag is set upon sending the START condition.
In case of an arbitration loss, the controller automatically switches back to target mode and
can acknowledge its own address if it is addressed as a target.
Note: The START bit is reset by hardware when the target address is sent on the bus, whatever
the received acknowledge value. The START bit is also reset by hardware upon arbitration
loss.
In 10-bit addressing mode, the controller automatically keeps resending the target address
in a loop until the first address byte (first seven address bits) is acknowledged by the target.
Setting the ADDRCF bit makes I2C quit that loop.
If the I2C peripheral is addressed as a target (ADDR = 1) while the START bit is set, the I2C
peripheral switches to target mode and the START bit is cleared when the ADDRCF bit is
set.
Note: The same procedure is applied for a repeated START condition. In this case, BUSY = 1.
Initialization of a controller receiver addressing a 10-bit address target
If the target address is in 10-bit format, the user can choose to send the complete read
sequence, by clearing the HEAD10R bit of the I2C_CR2 register. In this case, the controller
automatically sends the following complete sequence after the START bit is set:
(RE)START + Target address 10-bit header Write + Target address second byte +
(RE)START + Target address 10-bit header Read.
1 1 1 1 0 X X
Target address
S
Figure 260. Controller initialization flow
Enable interrupts and/or DMA in I2C_CR1
Figure 261. 10-bit address read access with HEAD10R = 0
0
Target address
R/W A1
1st 7 bits 2nd byte
Write
Inter-integrated circuit interface (I2C)
time after the BUSY flag transits from high to low
BUF
Controller
initialization
Initial settings
End
1 1 1 1 0 X X
Target address
A2 Sr
1st 7 bits
RM0366 Rev 5
1
R/W A3 DATA A
Read
MSv19859V3
DATA A P
MSv41066V2
