RM0366
19.5.7 TIM15 capture/compare mode register 1 (TIM15_CCMR1)
Address offset: 0x18
Reset value: 0x0000 0000
The same register can be used for input capture mode (this section) or for output compare
mode (next section). The direction of a channel is defined by configuring the corresponding
CCxS bits. All the other bits of this register have a different function in input and in output
mode.
Input capture mode:
31 30 29
Res. Res. Res. Res.
15 14 13
IC2F[3:0]
rw rw rw
Bits 31:16 Reserved, must be kept at reset value.
Bits 15:12 IC2F[3:0]: Input capture 2 filter
Bits 11:10 IC2PSC[1:0]: Input capture 2 prescaler
Bits 9:8 CC2S[1:0]: Capture/Compare 2 selection
This bit-field defines the direction of the channel (input/output) as well as the used input.
00: CC2 channel is configured as output
01: CC2 channel is configured as input, IC2 is mapped on TI2
10: CC2 channel is configured as input, IC2 is mapped on TI1
11: CC2 channel is configured as input, IC2 is mapped on TRC. This mode is working only if an
internal trigger input is selected through TS bit (TIMx_SMCR register)
Note: CC2S bits are writable only when the channel is OFF (CC2E = '0' in TIMx_CCER).
28 27 26 25
Res. Res. Res.
12 11 10 9
IC2PSC[1:0] CC2S[1:0]
rw rw rw rw
General-purpose timers (TIM15/TIM16/TIM17)
24 23 22
Res. Res. Res.
8 7 6
IC1F[3:0]
rw rw rw
RM0366 Rev 5
21 20 19 18
Res. Res. Res. Res.
5 4 3 2
IC1PSC[1:0]
rw rw rw rw
17 16
Res. Res.
1 0
CC1S[1:0]
rw rw
