Target byte control mode
To allow byte ACK control in target reception mode, the target byte control mode must be
enabled, by setting the SBC bit of the I2C_CR1 register. This is required to comply with
SMBus standards.
The reload mode must be selected to allow byte ACK control in target reception mode
(RELOAD = 1). To get control of each byte, NBYTES[7:0] must be initialized to 0x1 in the
ADDR interrupt subroutine, and reloaded to 0x1 after each received byte. When the byte is
received, the TCR bit is set, stretching the SCL signal low between the eighth and the ninth
SCL pulse. The user can read the data from the I2C_RXDR register, and then decide to
acknowledge it or not by configuring the ACK bit of the I2C_CR2 register. The SCL stretch is
released by programming NBYTES to a non-zero value: the acknowledge or
not-acknowledge is sent and the next byte can be received.
NBYTES[7:0] can be loaded with a value greater than 0x1. Receiving then continues until
the corresponding number of bytes are received.
Note: The SBC bit must be configured when the I2C peripheral is disabled, when the target is not
addressed, or when ADDR = 1.
The RELOAD bit value can be changed when ADDR = 1, or when TCR = 1.
Caution: The target byte control mode is not compatible with NOSTRETCH mode. Setting SBC when
NOSTRETCH = 1 is not allowed.
1. SBC must be set to support SMBus features.
Figure 252. Target initialization flow
Target
initialization
Initial settings
Clear OA1EN and OA2EN in I2C_OAR1/I2C_OAR2
Configure OA1[9:0], OA1MODE, OA1EN, OA2[6:0],
OA2MSK[2:0], OA2EN, and GCEN
Optional: Configure SBC in I2C_CR1
Enable interrupts and/or DMA in I2C_CR1
End
