ST STM32F301 6 Series Reference Manual page 586

Basic timers (TIM6)
Bit 31 UIFCPY: UIF Copy
This bit is a read-only copy of the UIF bit of the TIMx_ISR register. If the UIFREMAP bit in
TIMx_CR1 is reset, bit 31 is reserved and read as 0.
Bits 30:16 Reserved, must be kept at reset value.
Bits 15:0 CNT[15:0]: Counter value
20.4.7 TIM6 prescaler (TIM6_PSC)
Address offset: 0x28
Reset value: 0x0000
15 14 13
rw rw rw
Bits 15:0 PSC[15:0]: Prescaler value
The counter clock frequency CK_CNT is equal to f
PSC contains the value to be loaded into the active prescaler register at each update event.
(including when the counter is cleared through UG bit of TIMx_EGR register or through
trigger controller when configured in "reset mode").
20.4.8 TIM6 auto-reload register (TIM6_ARR)
Address offset: 0x2C
Reset value: 0xFFFF
15 14 13
rw rw rw
Bits 15:0 ARR[15:0]: Prescaler value
ARR is the value to be loaded into the actual auto-reload register.
Refer to
behavior.
The counter is blocked while the auto-reload value is null.
586/874
12 11 10 9
rw rw rw rw
12 11 10 9
rw rw rw rw
Section 20.3.1: Time-base unit on page 576
8 7 6
PSC[15:0]
rw rw rw
CK_PSC
8 7 6
ARR[15:0]
rw rw rw
RM0366 Rev 5
5 4 3 2
rw rw rw rw
/ (PSC[15:0] + 1).
5 4 3 2
rw rw rw rw
for more details about ARR update and
RM0366
1 0
rw rw
1 0
rw rw
