Direct memory access controller (DMA)
10.5 DMA interrupts
An interrupt can be generated on a half transfer, transfer complete, or transfer error for each
DMA channel x. Separate interrupt enable bits are available for flexibility.
Interrupt request
Half transfer on channel x
Transfer complete on channel x
Channel x interrupt
Transfer error on channel x
Half transfer or transfer complete or transfer error on channel x
10.6 DMA registers
Refer to
The DMA registers have to be accessed by words (32-bit).
10.6.1 DMA interrupt status register (DMA_ISR)
Address offset: 0x00
Reset value: 0x0000 0000
Every status bit is cleared by hardware when the software sets the corresponding clear bit
or the corresponding global clear bit CGIFx, in the DMA_IFCR register.
31 30 29
Res. Res. Res. Res.
15 14 13
TEIF4 HTIF4 TCIF4 GIF4
r r r
Bits 31:28 Reserved, must be kept at reset value.
Bit 27 TEIF7: Transfer error (TE) flag for channel 7
0: No TE event
1: A TE event occurred.
Bit 26 HTIF7: Half transfer (HT) flag for channel 7
0: No HT event
1: An HT event occurred.
Bit 25 TCIF7: Transfer complete (TC) flag for channel 7
0: No TC event
1: A TC event occurred.
Bit 24 GIF7: Global interrupt flag for channel 7
0: No TE, HT, or TC event
1: A TE, HT, or TC event occurred.
164/874
Table 26. DMA interrupt requests
Interrupt event
Section 1.2 for a list of abbreviations used in register descriptions.
28 27 26 25
TEIF7 HTIF7 TCIF7
r r r
12 11 10 9
TEIF3 HTIF3 TCIF3
r r r r
24 23 22
GIF7 TEIF6 HTIF6 TCIF6
r r r
8 7 6
GIF3 TEIF2 HTIF2 TCIF2
r r r
RM0366 Rev 5
Event flag
HTIFx
TCIFx
TEIFx
GIFx
21 20 19 18
GIF6 TEIF5 HTIF5
r r r r
5 4 3 2
GIF2 TEIF1 HTIF1
r r r r
RM0366
Interrupt
enable bit
HTIEx
TCIEx
TEIEx
-
17 16
TCIF5 GIF5
r r
1 0
TCIF1 GIF1
r r
