Revision 1
12. Copy the original ~sdc/senovision/scripts/light_adjustment file to the /export/home/extra_tmp/IPbak
directory for backup purposes, by entering:
cp ~sdc/senovision/scripts/light_adjustment /export/home/extra_tmp/IPbak/
light_adjustment.original
13. Open the ~sdc/senovision/scripts/light_adjustment file with the textedit command by entering:
textedit ~sdc/senovision/scripts/light_adjustment
The ~sdc/senovision/scripts/light_adjustment file appears in an X-Windows based TextEdit applica-
tion window.
14. Within the TextEdit application window, scroll down to the last line of the ~sdc/senovision/scripts/
light_adjustment script. Then change the reference of http://192.168.1.10 to match the new address
of the AWS (e.g. 192.168.100.10).
15. Save the ~sdc/senovision/scripts/light_adjustment file (File > Save) and click the
left of the TextEdit window to exit the editor.
16. Copy the newly modified ~sdc/senovision/scripts/light_adjustment file to the /export/home/extra_tmp/
IPbak directory for backup purposes, by entering:
cp ~sdc/senovision/scripts/light_adjustment /export/home/extra_tmp/IPbak/
light_adjustment.new
17. Copy the original ~sdc/senovision/config/PositionerServer.cfg file to the /export/home/extra_tmp/
IPbak directory for backup purposes, by entering:
cp ~sdc/senovision/config/PositionerServer.cfg /export/home/extra_tmp/
IPbak/PositionerServer.cfg.original
18. Open the ~sdc/senovision/config/PositionerServer.cfg file with the textedit command by entering:
textedit ~sdc/senovision/config/PositionerServer.cfg
The ~sdc/senovision/config/PositionerServer.cfg file appears in an X-Windows based TextEdit appli-
JC-ELE-A-050.fm
Service Information and Procedures Class A 2385072-16-8EN
Job Card ELE A050 - Changing Senographe Internal IP Addresses
Edit IP Address
Page no. 765
Senographe DS
button in the top
Chapter 7
- Quick Links:
- Err Sub A001 - Generator Error...
Hide quick links:
Advertisement
Table of Contents
Troubleshooting
Need help?
Do you have a question about the Senographe DS and is the answer not in the manual?
Questions and answers
G.E.Essential l have recently bought What is the full weight.of the mamo Full weight of the console and other İtem's also measurements of each item with the main machine please All this Shipping Company required
The GE Senographe DS mammography machine is shipped in three crates with the following dimensions and weights:
- Crate 1 (Gantry, Generator Cabinet, and ramp):
- Dimensions: 2066 mm (81.34 in) depth × 848 mm (33.39 in) width × 2292 mm (90.24 in) height
- Mass: 641 kg (1410.2 lbs)
- Crate 2 (Control Station):
- Dimensions: 1110 mm (43.70 in) depth × 770 mm (30.31 in) width × 1850 mm (72.83 in) height
- Mass: 210.5 kg (464.07 lbs) for truck transport (without side covers and lid)
- Mass: 223.5 kg (492.73 lbs) for plane/boat transport (with side covers and lid)
- Crate 3 (Detector):
- Dimensions: 872 mm (34.33 in) depth × 2270 mm (89.37 in) width × 260 mm (10.24 in) height
- Mass: 104.4 kg (229.68 lbs)
### Total Mass:
- For truck transport: 641 + 210.5 + 104.4 = 955.9 kg (2104.95 lbs)
- For plane/boat transport: 641 + 223.5 + 104.4 = 968.9 kg (2133.61 lbs)
These values include the gantry, generator cabinet, control station, detector, and all related components.
This answer is automatically generated
