GE Healthcare
Revision 1
Scenario ELE A001 - Electrical Installation
Step
Action
8
Configure Generator
9
Set Gantry travel limits
Checks
10
Generator Functional Checks
11
Refit Generator covers
12
Gantry Functional Checks
13
Collimation Checks
14
If you had remove the Gantry Covers
to get the Gantry into the room then
refit Gantry Covers
15
Manual Compression Check
Configuration
16
AWS configuration
17
Network connection and configuration
18
Optionally change the internal IP
address of the Senographe system
19
Declare Network Hosts
20
Declare Worklist Hosts
21
Declare Performed Procedure Step
Hosts
22
Declare Printers
23
Change the AOP configuration
24
Install Embedded Publications
Optional configuration
Chapter 7
Service Information and Procedures Class A 2385072-16-8EN
Job Card
Job Card ELE A009 - Generator Config-
uration on page 561
Job Card ELE A010 - Set Lift Travel
Limits on page 565
Job Card ELE A012 - X-ray Parameter
Check on page 571
Job Card PHY A042 - Remove/Reinstall
Generator Covers on page 513
Job Card ELE A015 - Gantry Functional
Checks on page 579
Job Card ELE A028 - Collimation
Checks on page 679
Job Card PHY A044 - Remove/Reinstall
Gantry Covers on page
Job Card ELE A017 - Manual Compres-
sion Check and Calibration on page 583
Job Card ELE A013 - AWS Configura-
tion on page 573
Job Card ELE A021 - Networking Con-
nection and Configuration on page 625
Job Card ELE A050 - Changing
Senographe Internal IP Addresses on
page 757
Job Card ELE A022 - Declare Network
Hosts on page 663
Job Card ELE A023 - Declare Worklist
Hosts on page 671
Job Card ELE A024 - Declare Per-
formed Procedure Step Hosts on page
675
Job Card ELE A020 - Declare and Set
Printers (Filming Devices) on page 585
Job Card ELE A031 - AOP Configura-
tion on page 693
Job Card ELE A044 - Install User Publi-
cations on page 755
Page no. 538
Senographe DS
Comments
523.
Optional.
Only required if the
hospital network is
the same as the
Senographe inter-
nal network
Done
SC-ELE-A-001.fm
- Quick Links:
- Err Sub A001 - Generator Error...
Hide quick links:
Advertisement
Table of Contents
Troubleshooting
Need help?
Do you have a question about the Senographe DS and is the answer not in the manual?
Questions and answers
G.E.Essential l have recently bought What is the full weight.of the mamo Full weight of the console and other İtem's also measurements of each item with the main machine please All this Shipping Company required
The GE Senographe DS mammography machine is shipped in three crates with the following dimensions and weights:
- Crate 1 (Gantry, Generator Cabinet, and ramp):
- Dimensions: 2066 mm (81.34 in) depth × 848 mm (33.39 in) width × 2292 mm (90.24 in) height
- Mass: 641 kg (1410.2 lbs)
- Crate 2 (Control Station):
- Dimensions: 1110 mm (43.70 in) depth × 770 mm (30.31 in) width × 1850 mm (72.83 in) height
- Mass: 210.5 kg (464.07 lbs) for truck transport (without side covers and lid)
- Mass: 223.5 kg (492.73 lbs) for plane/boat transport (with side covers and lid)
- Crate 3 (Detector):
- Dimensions: 872 mm (34.33 in) depth × 2270 mm (89.37 in) width × 260 mm (10.24 in) height
- Mass: 104.4 kg (229.68 lbs)
### Total Mass:
- For truck transport: 641 + 210.5 + 104.4 = 955.9 kg (2104.95 lbs)
- For plane/boat transport: 641 + 223.5 + 104.4 = 968.9 kg (2133.61 lbs)
These values include the gantry, generator cabinet, control station, detector, and all related components.
