Job Card TSG A001 - AWS Troubleshooting - No Display on Power Up
1-3
Monitor Adjustments and Power Checks
Connect the trackball/mouse to
the correct USB port (see
diagram on
page
82). Replace
USB extender if necessary.
Refer to monitor
video signal checks
on
page 1013
Chapter 9
Service Information and Procedures Class A 2385072-16-8EN
From
page 1010
AWS apparently powering up correctly,
but no display or poor display on monitor.
Is there a visible
display on the
monitor?
No
Check the AWS trackball
or mouse connection.
Yes
Is there a problem?
No
Is the monitor
operation LED lit?
Yes
No
Check the monitor power
cable. Is it wrongly
connected or defective?
No
Check the monitor
fuse. Is it defective?
No
If the problem persists, start again
on
page
1010, or ask for help from
your OLC.
Page no. 1012
Refer to LCD GS AWS Monitor
Service Manual for actions to
correct the display.
Yes
Reconnect or change the
monitor power cable.
Yes
Change the monitor fuse.
Yes
Senographe DS
JC-TSG-A-001.fm
