GE Senographe DS Manual page 1032

GE Healthcare
Revision 1
Job Card TSG A012 - Use of DB9 Adaptors to Reduce Intermittent IDC or ADS Communication Errors
TABLE 2 - IDC DB9 CONNECTIONS
DB9 cable connection reference in
illustration
ILLUSTRATION 3 - IDC DB9 CABLE CONNECTIONS
Chapter 9
1
2
3
Dione4
2
Dione5
Service Information and Procedures Class A 2385072-16-8EN
IDC - Gantry Conditioner Link 2226612
Detector Power Supply 2226621
IDC - Gantry Serial Link RT 2240227 or 2246615
3
Page no. 1032
Cable Label
1
2
3
1
Senographe DS
JC-TSG-A-012.fm
