Job Card PHY A004 - Radiation Screen Installation

1 SUPPLIES
1. A radiation screen is provided for standard installation as part of the Control Station.
2. A separate radiation screen can be provided as an option for when clients wish to use the X-ray Con-
sole in a position away from the Control Station, or where local regulations require a larger screen.
2 TOOLS
Standard Tool Box
3 REQUIRED EFFORT
Personnel: 2 Field Engineers
Time: 30 minutes
4 SAFETY PRECAUTIONS
Power to the system must be off before beginning the procedure.
5 PRE-REQUISITES
The Control Station have been secured to the floor in its correct position.
6 PROCEDURE - RADIATION SCREEN ON CONTROL STATION
CAUTION
Do not attempt to install the Radiation Screen on the Control Station cabinet before the
cabinet has been secured to the floor. Refer to
Station Installation on page
Station dangerously unstable.
6-1 Reception
The radiation screen is delivered on a single pallet, along with the digital detector, monitor and the
accessories. The Gantry and Generator Cabinet are delivered on another pallet. The Control Station is
delivered on another pallet. When a Senographe system arrives, check the entire consignment for dam-
age according to Job Card PRE A001 - Checking for Damage on page
JC-PHY-A-004.fm
Service Information and Procedures Class A 2385072-16-8EN
Job Card PHY A004 - Radiation Screen Installation
401. The Radiation Screen is heavy, and can make the Control
Page no. 405
Job Card PHY A003 - Gantry and Control
371.
