GE Senographe DS Manual page 874

GE Healthcare
Revision 1
ERR SUB A003 - Gantry Error Messages
Code Category
112/040 WARNING
112/041 WARNING
112/042 WARNING
112/043 WARNING
112/044 WARNING
Chapter 9
Text in Log File or
on LCD
VALID LINE WAS
ACTIVE ON ROTA-
TION NODE
ROTATION WAS
STOPPED WITH-
OUT STOP COM-
MAND
ROTATION NODE
SWITCH TO ANGU-
LATION MODE
FAILED
ROTATION NODE
SWITCH TO ROTA-
TION MODE FAILED
ANGULATION
CLUTCH NOT
READY
Service Information and Procedures Class A 2385072-16-8EN
Possible Cause/Recommended Action
The valid motion line is active at power-up.
1. Change the Gantry CPU Board (see
R A190 - Gantry CPU Board on page
2. Perform a Collimator Calibration (see
CAL A029 - Collimator Format Calibration on
page 1683).
3. Perform a Collimation Check (see
A028 - Collimation Checks on page
The rotation node stopped the motion by itself
because the button/pedal responsible for the motion
was released and no stop order was received before
the timeout.
1. Change the Gantry CPU Board (see
R A190 - Gantry CPU Board on page
2. Perform a Collimator Calibration (see
CAL A029 - Collimator Format Calibration on
page 1683).
3. Perform a Collimation Check (see
A028 - Collimation Checks on page
The rotation node failed to switch to angulation
mode.
Check the clutch position. If the clutch is not in angu-
lation mode (detector is locked), check the clutch
control, change the clutch device (after clutch control
check).
The rotation node failed to switch to rotation mode.
Check the clutch position. If the clutch is still in angu-
lation mode (detector is free), check the clutch con-
trol, change the clutch device (after clutch control
check).
At power-up, the rotation node checks that there is
no current through the clutch. This error occurs if:
• the operator requires several angulations in less
than 300 msec
• at power on there is no current into the clutch
• clutch stays locked to the detector on angulation
request, check clutch operation at several angles
(45° to 90°).
Refer to JC DIAG A1111 ROTATION CLUTCH FAIL-
URE on page 952 to fix the problem.
Page no. 874
Senographe DS
Job Card
D/R A190
page
1131
Job Card D/
1131).
CAL A029
Job Card
page
1683
Job Card ELE
ELE A028
679).
page 679
D/R A190
page
1131
CAL A029
page
Job Card D/
1683
1131).
Job Card
ELE A028
page 679
Job Card ELE
679).
A1111
page 952
ERR-SUB-A-003.fm
