GE Senographe DS Manual page 1209

GE Healthcare
Revision 1
3-7-1 Detector Covers - non-available covers
• If the reference of the defective part appears in the following table, it cannot be replaced individually.
A complete set of covers must be ordered and installed:
- Order a set of covers as listed below:
• The Detector must be modified to accept the new covers. Refer to
• The new Detector/Positioner Interface Plate reference 2408213, together with the new Quick Fix
Assembly, reference 2411952, must be installed in place of the existing Interface Plate. Refer to
tion 3-10 page 1212.
• After modifying the detector and changing the interface plate, install the new covers using the infor-
mation given in Job Card PHY A044 - Remove/Reinstall Gantry
3-7-2 Detector Covers - available covers
If the reference of the defective part appears in the following table, it can be replaced individually.
The table indicates the necessary part(s) to be ordered
If the defective part is:
2375024-2
2375025-2
• Install the new cover(s) using the information given in
try Covers, section 10 page
JC-DR-A-210.fm
Reference
2375024
2375025
Reference
2375024-2
2375025-2
2411952 Quick Fix Assy for Detector Covers
2408213
Detector Cover Upper
Detector Cover Lower
530.
Service Information and Procedures Class A 2385072-16-8EN
Job Card D/R A210 - Gantry cover replacement guide
2375024-3 Detector Cover Upper
2375025-3 Detector Cover Lower
Description
Detector Cover Upper
Detector Cover Lower
Interface Plate Equipped
Order the following parts:
Reference
2375024-2
2375025-2
Job Card PHY A044 - Remove/Reinstall Gan-
Page no. 1209
Description
Quantity
1
1
1
1
section 3-9 page
Covers, section 10 page
Description
Detector Cover Upper
Detector Cover Lower
Senographe DS
1211.
sec-
530.
Quantity
1
1
Chapter 9
