GE Senographe DS Manual page 885

GE Healthcare
Revision 1
Code Category
122/026 HALT
122/027 N/A
122/028 HALT
122/029 HALT
122/030 HALT
ERR-SUB-A-003.fm
Service Information and Procedures Class A 2385072-16-8EN
Text in Log File or
on LCD
COMPRESSION Occurs when the parity bit does not set correctly on
NODE PARITY the on-board bus between the CPLD and the MCU.
ERROR
1. Change the Compression Board.
2. Perform a calibration of the Compression Force
3. Perform a Compression Thickness calibration.
STOP LINE WAS The main CPU detected an error and activated the
ACTIVATED BY stop motion line or did not deactivated it at all.
CPU
Ignore this error. If the problem persists, contact your
OLC.
LOW VOLTAGE If the voltage of the power supply falls below 24 V
ERROR ON COM- the node sends this error.
PRESSION NODE
1. Change the Compression Board.
2. Perform a calibration of the Compression Force
3. Perform a Compression Thickness calibration.
COMPRESSION If the MCU does not react on the IRQ coming from
READ TIMEOUT the CPLD before 15 ms, the node sends this error.
ERROR
1. Change the Compression Board.
2. Perform a calibration of the Compression Force
3. Perform a Compression Thickness calibration.
COMPRESSION Test data from the CPLD is periodically read to
CPLD MEMORY ensure the proper communication. If this error does
ERROR not match the node sends this error.
1. Change the Compression Board.
2. Perform a calibration of the Compression Force
3. Perform a Compression Thickness calibration.
ERR SUB A003 - Gantry Error Messages
Possible Cause/Recommended Action
Sensor.
Sensor.
Sensor.
Sensor.
Page no. 885
Senographe DS
Job Card
D/R A250
page
1323
CAL A048
page
1709
CAL A050
page
1721
D/R A250
page
1323
CAL A048
page
1709
CAL A050
page
1721
D/R A250
page
1323
CAL A048
page
1709
CAL A050
page
1721
D/R A250
page
1323
CAL A048
page
1709
CAL A050
page
1721
Chapter 9
