Code Category
132/018 INHIBIT
132/019 INHIBIT
132/020 INHIBIT
132/021 INHIBIT
132/022 INHIBIT
132/023 INHIBIT
ERR-SUB-A-003.fm
Text in Log File or
on LCD
TILT COMMAND
SEQUENCE IS
INCORRECT
TILT MCU CALI-
BRATION DATA
CORRUPT
TILT MCU EEPROM
FAILURE
TILT CAN COM-
MAND NOT PRO-
CESSED
TILT CAN BUFFER
OVERRUN
TILT MAILBOX
OVERRUN
Service Information and Procedures Class A 2385072-16-8EN
Possible Cause/Recommended Action
The checksum on the calibration data stored by the
MCU does not match.
Change the Tilt board then perform a Tilt Calibration.
The checksum on the calibration data stored by the
MCU does not match.
Perform the tube tilt calibration, if the problem per-
sists, change the tube tilt board.
The readback on the newly written data to the
EEPROM failed.
Change the Tilt board then perform a Tilt Calibration.
The CAN command was not processed. The Gantry
CPU has sent command to the compression node
before the compression node could acknowledge the
previous command.
1. Change the Gantry CPU Board (see
R A190 - Gantry CPU Board on page
2. Perform a Collimator Calibration (see
CAL A029 - Collimator Format Calibration on
page 1683).
3. Perform a Collimation Check (see
A028 - Collimation Checks on page
The input queue of the incoming CAN messages of
the MCU is full and message dropped.
Reboot the complete system. If the problem persists,
check the other nodes (not tube tilt). If other nodes
are good, check the tube tilt node (cabling, board).
The mailbox queue used in the inter-task communi-
cation in the MCU is full and mails dropped.
Change the Tilt board then perform a Tilt Calibration.
Page no. 895
ERR SUB A003 - Gantry Error Messages
Job Card D/
1131).
Job Card
Job Card ELE
679).
Senographe DS
Job Card
D/R A266
page
1365
CAL A027
page
1681
CAL A027
page
1681
D/R A266
page
1365
D/R A266
page
1365
CAL A027
page
1681
D/R A190
page
1131
CAL A029
page
1683
ELE A028
page 679
D/R A266
page
1365
CAL A027
page
1681
