ERR SUB A001 - Generator Error Messages

1 INTRODUCTION
This Job Card lists error codes generated by the Generator sub-system and displayed on the X-ray Con-
sole. Each message can contain two codes, the User error code and the Service error code (refer to the
explanation below). Error codes containing a Service Error Code are listed here; codes containing a
User Error code are listed in the Senographe DS Operator Manual. Many messages contain both, and
appear in both manuals.
Refer to Section 3 Error Code Structure for an explanation of the error code display.
Section 4 Generator Error Codes lists the error codes, with corresponding error descriptions. Where pos-
sible (mainly for recently developed codes), the list also includes the text of a displayed error message,
and suggestions for corrective action.
2 HOW TO VIEW THE ERROR LOG
Errors reported by the Generator sub-systems are recorded in a common system error log which also
contains error messages generated by the AWS and IDC.
To view the error log content, right click the AWS Screen background; select Service Tools/Service
Desktop/Error Log from the drop-down menu.
3 ERROR CODE STRUCTURE
Error codes are displayed on the X-ray Console in the format shown here:.
E
a
User error code
• The User Error Code is the code given in the Senographe DS Operator Manual. It is easy to use and
communicate, and gives sufficient information for use by the Operator.
It includes a code for the type of error (a) and a message number (bb). The example given, E55, indi-
cates that a tube inhalation fault has occurred which caused exposure inhibition,
- a: Type of error:
I: Warning; exposure not inhibited.
S: Warning; exposure inhibited.
E: Fault; exposure inhibited.
K: Fault; power shut down for safety.
- bb: Message number indicating the origin of the fault.
• The Service Error Code is the code used in this document; it gives more information, and is recom-
mended for use in GE internal communication. It includes two reference codes:
- ccc: Indicates the affected subassembly (hardware or software). The example given, 161, indi-
cates a tube housing fault.
- ddd: Indicates the origin of the fault The example given, 013, indicates that no reference crossing
was detected during tube movement.
