Gantry Mpcb Switches And Fuses - GE Senographe DS Manual

GE Healthcare
Revision 1
5.

GANTRY MPCB SWITCHES AND FUSES

5-1. MPCB Fuses
Fuse
F1
F2
Indicators and Switches.fm
Stop Motion button -
(one either side of column.
PDU Board PL101
(for fuses, etc., see
PL101 on page
F1/F2 Fuse, 600 Vac, 20 A, Fast
Circuit Breaker 10 A
Specification
600 Vac, 20 A, Fast
Service Information and Procedures Class A 2385072-16-8EN
Left.
PDU Board
290).
PN
2387747
Page no. 297
Senographe DS
Central Listing
Function
Chapter 3
