GE Senographe DS Manual page 866

GE Healthcare
Revision 1
ERR SUB A003 - Gantry Error Messages
Code Category
111/001 DEBUG
ONLY
111/002 DEBUG
ONLY
111/003 WARNING
111/004 WARNING
Chapter 9
Service Information and Procedures Class A 2385072-16-8EN
Text in Log File or
on LCD
ROTATION SOFT- On every command sent by the PTB, the IPMS
WARE ERROR checks whether the command identifier is part of the
list of commands to be taken into account by the
IPMS. If the command is not recognized, it is
ignored, and "CommandIdError" is returned.
Should not occur in the field. It could be a disconnect
between the CPU soft release and the Node soft
release. If the problem persists, contact your OLC.
ROTATION SOFT- On every command sent by the PTB, the IPMS
WARE ERROR checks whether all the parameter values are com-
patible with their corresponding range. If they are not
compatible, the IPMS ignores the command and
returns the "ParameterError" to the PTB.
Should not occur in the field. It could be a disconnect
between the CPU soft release and the Node soft
release. If the problem persists, contact your OLC.
ROTATION CALIB If the calibration has not been achieved, for each
NOT ACHIEVED CAN message which is not a calibration command,
the IPMS ignores the command and returns the "Cal-
ibrationNotAchieved" error.
Perform
tion on page
NO VALID LINE Occurs when the Gantry CPU requests a motion but
FOR ROTATION node does not see the valid line. The valid line is an
RT line that is activated by the CPLD of the node
containing the UIF during the time when the UIF is
pressed + a deceleration time. This activation is a
frequency put on the RT line and that is specific to
the button pressed (Tube Head and/or X-ray Con-
sole).
Also occurs when the valid line falls before the end of
the movement.
This error does not concern decompression and tilt.
Valid line problem. Check the different motions,
using all keypads to determine the defective node
then refer to
FAILURE on page 954
Possible Cause/Recommended Action
Job Card CAL A021 - Arm Rotation Calibra-
1679.
JC DIAG A1116 ROTATION CONTROL
for diagnostics.
Page no. 866
Senographe DS
Job Card
CAL A021
page
1679
DIAG
A1116
page 954
ERR-SUB-A-003.fm
