GE Healthcare
Revision 1
ERR SUB A003 - Gantry Error Messages
3
GANTRY WARNING MESSAGES
3-1
Error Codes from 100/yyy: Lift
Code
Category
100/001
HALT
100/002
HALT
100/003
HALT
Chapter 9
Service Information and Procedures Class A 2385072-16-8EN
Text in Log File or
on LCD
LIFT HARDWARE
There is a relay defect at power-up. A relay (on the
ERROR
board) is mounted in parallel with the H-bridge of the
motor. When this relay is closed it creates a short-cut
of the H-bridge. At power-up, the lift node injects
15 V to the H-Bridge, shuts the relay and checks that
there is 0 V. The lift node re-opens the relay and
checks that there is 15 V. If the lift node does not
perform this routine, this error is produced.
This error typically occurs in conjunction with a HALT
POSTION error (such as rotation, compression,
etc.), in which case the Lift Board is not faulty. Pro-
ceed as follows:
1. Reboot the system. Check the error logs to see
2. If a POSITION ERROR (e.g. rotation or com-
3. If a POSITION ERROR (e.g. rotation or com-
LIFT SENSOR
Upper Optical Fork failure. At power-up, the lift node
DEFECT
shuts down the LED of the optical fork, and checks
that the photoresistor shuts down. Optical forks are
hardware limits hence they are never obturated.
Faulty FRU = Upper Optical Fork.
Change the FRU and reboot Gantry.
LIFT SENSOR
Lower Optical Fork failure. At power-up, the lift node
DEFECT
shuts down the LED of the optical fork, and checks
that the photoresistor shuts down. Optical forks are
hardware limits hence they are never obturated.
Faulty FRU = Lower Optical Fork.
Change the FRU and reboot Gantry.
Possible Cause/Recommended Action
whether the 100/001 LIFT HARDWARE ERROR
occurs within the same time as another POSI-
TION ERROR (e.g. rotation or compression).
pression) does exist within the same time, ignore
the 100/001 LIFT HARDWARE ERROR. Do not
change the Lift Board, and take appropriate
action to resolve the POSITION ERROR.
pression) does not exist within the same time,
the 100/001 LIFT HARDWARE ERROR is valid.
You must change the Lift Board and then recali-
brate the Lift.
Page no. 852
Senographe DS
Job Card
D/R A201
page
1161
CAL A031
page
1687
ERR-SUB-A-003.fm
