GE Healthcare
Revision 1
4. At the Hostname screen, type the Hostname to be used for the Acquisition Workstation in the Host-
name field, and press <Return> when done. Then press the <F2> key to continue.
- Hostname - - - - - - - - - - - - - - - - - - - - - - - - - - - -
On this screen .................................
A host name must be .............................
.................................................
Note:
The Hostname will automatically be used as the DICOM A.E. Title for the workstation. If there is
more than one Senographe system on the hospital site, the names chosen must clearly differenti-
ate between them. For example, by include the unit number or name.
Do not use the following characters in the Hostname:
!
$ "
ONLY USE ALPHANUMERIC CHARACTERS WITHOUT SPACES.
It is also possible to use the characters - (dash) and . (dot).
Ensure that the Hostname is no more than 12 characters long.
The Hostname must be the same value as the Station Name that is defined in
- AWS Configuration on page
5. At the IP Address screen, type the external IP address to be used for the Acquisition Workstation in
the IP address field, and press the <Return> key when done. Then press the <F2> key to continue.
- IP Address - - - - - - - - - - - - - - - - - - - - - - - - - - -
On this screen .................................
IP addresses must .............................
.................................................
6. At the Subnets screen, ensure that Yes is selected for the System part of a subnet option, and press
the <F2> key to continue.
- Subnets - - - - - - - - - - - - - - - - - - - - - - - - - - - -
On this screen .................................
> To make a selection .............................
.................................................
JC-ELE-A-021.fm
Hostname :
'
'
{ }
[
]
*
573.
IP address :
System part of a subnet :
X
Service Information and Procedures Class A 2385072-16-8EN
Job Card ELE A021 - Networking Connection and Configuration
@ # ? ^ _ / etc.
Yes
No
Page no. 629
Senographe DS
Job Card ELE A013
Chapter 7
