GE Senographe DS Manual page 881

GE Healthcare
Revision 1
Code Category
122/001 HALT
122/002 HALT
122/003 HALT
122/004 N/A
ERR-SUB-A-003.fm
Text in Log File or
on LCD
COMPRESSION
SOFTWARE
ERROR
COMPR POTENTI-
OMETER DEFECT
COMPRESSION
ENCODER DEFECT
COMP MOTION
UNCOHERENT
Service Information and Procedures Class A 2385072-16-8EN
Possible Cause/Recommended Action
The watch-dog receives a pulse from microcontroller
every 40 ms. If not, it resets the microcontroller,
node restarts and sends a boot-up signal to Gantry
CPU. The only possible reason for a boot-up of a
node after system power-up is a reset by watchdog.
Therefore, when Gantry CPU receives the boot-up
signal, it produces the SWOverRun error.
1. Change the Compression Board (Firmware prob-
lem: microcontroller or clock CPLD issue).
2. Perform a calibration of the Compression Force
Sensor.
3. Perform a Compression Thickness calibration.
There is a potentiometer defect. At all time, the node
checks that the signal coming from potentiometer is
within an acceptable range. If not, it sends this sig-
nal.
See JC DIAG A1214 COMPRESSION CONTROL
FAILURE on page 961
For every node equipped with a coding wheel. If a
coding wheel defect is detected through the comple-
mented HW lines, the IPMS stops, and forbids the
motion, and sends an error message.
The signal coming from motor encoder contains four
phases. A, A complementary, B, B complementary.
Node checks two things: complementarity +
sequence of phases.
See JC DIAG A1203 COMPRESSION CONTROL
FAILURE on page 957
The IPMS sends a CAN message to ask a stop
motion to system (message IPMS_SRS_ERR_023).
On every node except compression, this check is
performed on relative and absolute coders. On the
compression node, only the relative coder is
checked due to the manual compression ability.
(Occurs when pulses are sent by the coder whereas
the IPMS considers that there must not be any
motion. This check concerns Lift, Rotation, Com-
pression, and Tilt).
See JC DIAG A1203 COMPRESSION CONTROL
FAILURE on page 957
Page no. 881
ERR SUB A003 - Gantry Error Messages
to fix the problem.
to fix the problem.
to fix the problem.
Senographe DS
Job Card
D/R A250
page
1323
CAL A048
page
1709
CAL A050
page
1721
A1214
page 961
A1203
page 957
A1203
page 957
Chapter 9
