GE Healthcare
Revision 1
Job Card D/R A150 - System Fuses
2
TOOLS
Standard Tool Box
3
REQUIRED EFFORT
Personnel: 1 Field Engineer
Time: Approximately 60 minutes
4
SAFETY PRECAUTIONS
WARNING
The Senographe system must be powered off and LOTO applied. Switch off the electrical
power supply from the Mains Distribution Panel in the room. Apply an appropriate LOTO
padlock and label. If changing a fuse within the Generator, wait 10 minutes for the compo-
nents within the Generator to discharge.
5
PREREQUISITES
You will have probably already removed the Generator or Gantry covers during trouble-shooting tasks to
determine you need to change a fuse. However, if necessary, do the following:
•
If you are changing fuses on the Compression Board, remove the Compression Arm covers to
access the Compression Board. Refer to
Covers on page
•
If you are changing fuses on the PDU Board, remove the Column covers to access the PDU Board.
Refer to
section 7
•
If you are changing a fuse on one of the boards in the Generator, remove the Generator covers.
Refer to
Job Card PHY A042 - Remove/Reinstall Generator Covers on page
5-1
Ensure Capacitors on Generator Boards are Discharged
If you are changing a fuse on one of the Generator boards, ensure that the capacitors are fully dis-
charged before touching the fuses on those boards. For more information, refer to the one of the appro-
priate sections below:
•
section
5-1-1,
Ensure that the Generator Command Board Capacitors are Discharged on page 1111
•
section
5-1-2,
Ensure that the Generator Supply Command Board Capacitors are Discharged on
page 1112
•
section
5-1-3,
Ensure that the Mains Distribution Board Capacitors are Discharged on page 1115
Chapter 9
523.
in
Job Card PHY A044 - Remove/Reinstall Gantry Covers on page
Service Information and Procedures Class A 2385072-16-8EN
section 8
in
Job Card PHY A044 - Remove/Reinstall Gantry
Page no. 1110
Senographe DS
523.
513.
JC-DR-A-150.fm
- Quick Links:
- Err Sub A001 - Generator Error...
Hide quick links:
Advertisement
Table of Contents
Troubleshooting
Need help?
Do you have a question about the Senographe DS and is the answer not in the manual?
Questions and answers
G.E.Essential l have recently bought What is the full weight.of the mamo Full weight of the console and other İtem's also measurements of each item with the main machine please All this Shipping Company required
The GE Senographe DS mammography machine is shipped in three crates with the following dimensions and weights:
- Crate 1 (Gantry, Generator Cabinet, and ramp):
- Dimensions: 2066 mm (81.34 in) depth × 848 mm (33.39 in) width × 2292 mm (90.24 in) height
- Mass: 641 kg (1410.2 lbs)
- Crate 2 (Control Station):
- Dimensions: 1110 mm (43.70 in) depth × 770 mm (30.31 in) width × 1850 mm (72.83 in) height
- Mass: 210.5 kg (464.07 lbs) for truck transport (without side covers and lid)
- Mass: 223.5 kg (492.73 lbs) for plane/boat transport (with side covers and lid)
- Crate 3 (Detector):
- Dimensions: 872 mm (34.33 in) depth × 2270 mm (89.37 in) width × 260 mm (10.24 in) height
- Mass: 104.4 kg (229.68 lbs)
### Total Mass:
- For truck transport: 641 + 210.5 + 104.4 = 955.9 kg (2104.95 lbs)
- For plane/boat transport: 641 + 223.5 + 104.4 = 968.9 kg (2133.61 lbs)
These values include the gantry, generator cabinet, control station, detector, and all related components.
