GE Healthcare
Revision 1
Code
Category
112/035
HALT
112/036
HALT
112/037
HALT
112/038
DEBUG
ONLY
112/039
HALT
ERR-SUB-A-003.fm
Text in Log File or
on LCD
ROTATION TX CAN
BUFFER OVERRUN
ROTATION MAIL-
BOX OVERRUN
CPU HEARTBEAT
NOT RECEIVED BY
ROTATION NODE
HEARTBEAT DIS-
ABLED ON ROTA-
TION NODE
ROTATION INVALID
PDO LENGTH
Service Information and Procedures Class A 2385072-16-8EN
Possible Cause/Recommended Action
The transmit queue between the MCU and the DSP
is full and message dropped.
Change the Rotation board then perform a Rotation
Calibration.
The mailbox queue used in the inter-task communi-
cation in the MCU is full and mails dropped.
Change the Rotation board then perform a Rotation
Calibration.
There has been a heartbeat failure. The Gantry CPU
did not send periodic "heartbeat" CAN message.
1. Change the Gantry CPU Board (see
R A190 - Gantry CPU Board on page
2. Perform a Collimator Calibration (see
CAL A029 - Collimator Format Calibration on
page
1683).
3. Perform a Collimation Check (see
A028 - Collimation Checks on page
The Gantry CPU tried to disable the "heartbeat"
check of the rotation node.
1. Change the Gantry CPU Board (see
R A190 - Gantry CPU Board on page
2. Perform a Collimator Calibration (see
CAL A029 - Collimator Format Calibration on
page
1683).
3. Perform a Collimation Check (see
A028 - Collimation Checks on page
The rotation node receives a PDO with an invalid
DLC.
Refer to
JC DIAG A1117 ROTATION COMMUNICA-
TION FAILURE on page 955
Page no. 873
ERR SUB A003 - Gantry Error Messages
Job Card D/
1131).
Job Card
Job Card ELE
679).
Job Card D/
1131).
Job Card
Job Card ELE
679).
to fix the problem.
Senographe DS
Job Card
D/R A221
page
1223
CAL 021
page
1679
D/R A221
page
1223
CAL 021
page
1679
D/R A190
page
1131
CAL A029
page
1683
ELE A028
page 679
D/R A190
page
1131
CAL A029
page
1683
ELE A028
page 679
A1117
page 955
