Job Card TSG A010 - Troubleshooting Bad Pixel Calibration Failure
ILLUSTRATION 1 - HIGH-LEVEL OVERVIEW OF THE BAD PIXEL CALIBRATION PROCESS
IQ check image:
First exposure
3-1 Troubleshooting - Failure at the End of IQ Check Image
Follow the appropriate sub-section below according to the IQ check test message you received.
3-1-1 IQ Check Test - Median Signal Level
The purpose of this test is to check that the system configuration is correct and that the correct phantom
has been placed on the detector. If this test fails, the calibration is aborted and the following message
appears:
"brightness level is not OK"
3-1-1-1 Typical Root Causes
1. The system is not correctly configured for bad pixel calibration (i.e. a compression paddle or a bucky
is in place).
2. The kV scale factor of the X-Ray tube is too high or too low.
3. The mAs measurement of the X-Ray tube is too high or too low.
4. The detector temperature is out of range.
3-1-1-2 Corrective Actions
1. Ensure that the bucky is removed, and that no compression paddle is installed. Then perform bad
pixel calibration with the flat field phantom as instructed.
2. If the problem persists, perform
kV Scale Factor, to see if the kV Scale Factor is within the correct limits. If the kV Scale Factor results
fail, re-calibrate the kV scale factor according to
on page 1667. After kV scale factor calibration has been performed, go to
be performed after a kV scale factor calibration on page 1026
list.
3. If the problem persists, perform
Measurement , to see if the mAs of the X-Ray tube is within the correct limits. If the mAs results fail,
re-calibrate the mAs of the X - Ray tube according to
surement on page
to be performed after an X-Ray tube mA measurement on page 1027
