Scenario PHY A001 - Physical Installation

1 CONTEXT
This Scenario provides information for the physical phase of a first installation of Senographe equipment
on the customer site.
The installation is split into two phases:
• Physical installation: positioning and cabling the various sub-systems without applying power. This is
treated in this scenario.
• Electrical installation: powering on the system, configuration, and verification, up to start-up with the
customer. Refer to chapter
2 STEERING GUIDE
Refer to the following Steering Guide for an outline of the recommended sequence of physical installa-
tion.
Physical Installation Steering Guide - Preparation, Physical Installation, and Connection.
Step
Preparation
1 Schedule appointments: Delivery date,
movers, etc.
2 Check room preparation (See PIM inspec-
tion report and the structural engineer site
survey report)
Physical Installation
3 Unpack Generator and Gantry pallet
Move Generator + Gantry to X-ray room
4 If the hospital doors are too low for the
height of the Gantry with its covers on,
remove the Gantry Covers
5 If the hospital site does not allow you to
transport the Generator and Gantry
together, disconnect them and move them
individually into the X-ray room
6 Unpack Control Station
Move Control Station to X-ray room
7 Establish the optimum positions for Gan-
try, Generator, and Control Station and
decide whether the LCD Monitor must be
mounted on the other side.
Obtain the customer agreement.
Anchor the Gantry and the Control Station
SC-PHY-A-001.fm
Service Information and Procedures Class A 2385072-16-8EN
7 Electrical Installation on page
Job Card PHY A001 - Unpacking the
Gantry and Generator Cabinet on
Job Card PHY A044 - Remove/Rein-
stall Gantry Covers on page
Generator Disconnection Procedure
on page 483
Generator and Gantry Disconnection
Job Card PHY A002 - Unpacking the
Job Card PHY A003 - Gantry and
Control Station Installation on page
Page no. 389
Scenario PHY A001 - Physical Installation
535.
Job Card
None
None
page 391
in Job Card PHY A030 -
Reconnection
Control Station on page 397
401
Senographe DS
Chapter 6
Comments
Two
persons
required
523.
Two
persons
required
Chapter 6
Done
