3-1-3. Mains Distribution Assembly Configuration Jumpers
Jumper Default
Setting
TP1 OFF
(Open)
TP2 OFF
(Open)
TP3 ON
(Closed)
3-1-4. Mains Distribution Assembly Fuses
Fuse
F1 250 Vac, 10 A, Delay
F2 250 Vac, 5 A, Delay
F4
F3 250 Vac, 1.6 A, Delay
F5 250 Vac, 1.0 A, Delay
Chapter 3
Control Station Power OFF function.
If TP1 is OFF (as required), the Control Station cannot
• cannot be powered off by the Generator Control Buttons
• cannot be powered off by the X-ray Console Power button
• it is powered off by the ADS shutdown process
Conditioner auto power off enabled.
If the TP2 jumper is OFF (as required), the Conditioner is always ON even
when the Generator is powered OFF.
DPS auto power off enabled.
If TP3 is ON (as required), the DPS is switched OFF by system.
Specification
Service Information and Procedures Class A 2385072-16-8EN
Function
PN
99183979 Power Supply (XP4) to Control Station (UPS)
99183923 Power Supply (XP5) to Detector Power Supply input
Line Power Voltage Input to Conditioner (J2 - LED
99183925 Power Supply to Low Voltage Power Supply input
99183936 + 12V from Low Voltage Power Supply
