GE Healthcare
Revision 1
ERR SUB A003 - Gantry Error Messages
Code
Category
164/004
INHIBIT
164/005
INHIBIT
164/006
INHIBIT
164/008
INHIBIT
165/000
INHIBIT
165/001
INHIBIT
165/002
INHIBIT
Chapter 9
Text in Log File or
on LCD
COMMUNICATION
ERROR WITH COL-
LIMATOR NODE
INTERNAL SOFT-
WARE ERROR
COLLIMATOR CON-
TROL ERROR
COLLIMATOR
NODE NOT
RESPONDING
Internal software
error
Internal software
error
Internal software
error
Service Information and Procedures Class A 2385072-16-8EN
Possible Cause/Recommended Action
The Gantry CPU was unable to load the collimator
parameters.
Reboot the system from the X-ray Console. If the
problem persists, contact your OLC.
The Gantry CPU received an unknown error code
from the collimator node.
Reboot the system from the X-ray Console. If the
problem persists, contact your OLC.
The collimator node did not start. At power-up, the
collimator node sends an acknowledgment (which
can be different from the first heartbeat signal) to
Gantry CPU. If the collimator node does not send an
acknowledgment, the Gantry CPU creates this error.
Reboot the system from the X-ray Console. If the
problem persists, contact your OLC.
The collimator node did not send the Heartbeat sig-
nal.
Between two motions, the collimator node sends a
Heartbeat signal every second to Gantry CPU. If not,
the Gantry CPU creates this error.
During lift motion, the lift collimator sends an actual
value message regularly in addition to the heartbeat.
If not, the Gantry CPU creates this error.
Reboot the system from the X-ray Console. If the
problem persists, contact your OLC.
There is an invalid serial port configuration, and
therefore no communication is possible between the
Gantry CPU and the Generator.
Reboot the system from the X-ray Console. If the
problem persists, contact your OLC.
There is a hardware error with the COM port, and
therefore no communication is possible between the
Gantry CPU and the Generator.
Reboot the system from the X-ray Console. If the
problem persists, contact your OLC.
Received message number does not match.
Reboot the system from the X-ray Console. If the
problem persists, contact your OLC.
Page no. 922
Senographe DS
Job Card
ERR-SUB-A-003.fm
