GE Healthcare
Revision 1
Central Listing
2-9-2.
kVmA Board 700PL1 LEDs
LED
DS1
DS2
Chapter 3
Function
-15 V Present
+15 V Present
Service Information and Procedures Class A 2385072-16-8EN
Color
Green
Normal status: ON
ON when the -15V from the Generator Command
Board 400PL1 is present.
OFF when there is a problem with the -15V from
the Generator Command Board 400PL1. In this
case, proceed as follows:
• Check the status of the 12 V on the Generator
Command Board 400PL1 indicated by its green
DS9 LED.
If the DS9 LED is ON, change the cable between
the XJ1 connector on the kVmA Board and the
XJ5 connector on the Generator Command Board
400PL1.
• If the problem persists, change the HV Tank.
Green
Normal status: ON
ON when the +15 V from the Generator Command
Board 400PL1 is present.
OFF when there is a problem with the +15 V from
the Generator Command Board 400PL1. In this
case, proceed as follows:
• Check the status of the 12 V on the Generator
Command Board 400PL1 indicated by its green
DS9 LED.
If the DS9 LED is ON, change the cable between
the XJ1 connector on the kVmA Board and the
XJ5 connector on the Generator Command Board
400PL1.
• If the problem persists, change the HV Tank.
Page no. 276
Senographe DS
Behavior
Indicators and Switches.fm
