Pre-Installation System Requirements
10-2-4. Layout Examples
The following illustrations provide some example layouts which adhere to the constraints listed above.
Each layout example contains a non-USA and a USA version, where the USA versions adhere to OSHA
Egress safety standard of 28" (711 mm).
Note:
Ensure that the room layout is adapted to the cable length constraints as listed in the table below
and as summarized in section 10-4.
Gantry to Control Station cables in Harness 1
Gantry to Generator cables in Harness 2
Generator to Control Station: X-ray Console Cable
Note:
If a separate radiation screen is used instead of the integrated radiation screen, the Control Station
must positioned so that the LCD Monitor cannot collide with the integrated radiation screen.
Note:
If the room size is small such that it restricts the positioning of the Control Station so that it is close
to a wall or separate radiation screen, the Rotative Arm securing the LCD Monitor can be adjusted
so that it does not move.
Chapter 4
Service Information and Procedures Class A 2385072-16-8EN
Cable/Harness
The X-ray Console cable is integrated within the
two harnesses.
If the X-ray Console cable is separated from the
harnesses its total usable length is 10 m (32.8").
Page no. 348
Senographe DS
Length
4.8 m (15.75")
3.8 m (14.9")
