GE Healthcare
Revision 1
Code
Category
165/003
INHIBIT
165/004
INHIBIT
165/005
INHIBIT
165/006
INHIBIT
165/007
INHIBIT
165/008
INHIBIT
165/009
DEBUG
ONLY
165/010
INHIBIT
165/011
INHIBIT
165/014
INHIBIT
ERR-SUB-A-003.fm
Service Information and Procedures Class A 2385072-16-8EN
Text in Log File or
on LCD
Internal software
Received message BCC does not match.
error
Reboot the system from the X-ray Console. If the
problem persists, contact your OLC.
Internal software
RX Buffer FULL.
error
Reboot the system from the X-ray Console. If the
problem persists, contact your OLC.
Internal software
TX Buffer FULL.
error
Reboot the system from the X-ray Console. If the
problem persists, contact your OLC.
GENERATOR DIS-
A message from the Gantry CPU can not be sent to
CONNECTED
Generator because Generator is not connected or
powered down.
Check cable connections between the Generator
and the Gantry CPU Board.
Reboot the system from the X-ray Console. If the
problem persists, contact your OLC.
Internal software
Events count not found.
error
Reboot the system from the X-ray Console. If the
problem persists, contact your OLC.
Internal software
Event number from the list not defined.
error
Reboot the system from the X-ray Console. If the
problem persists, contact your OLC.
Internal software
Revision description not found in file.
error
Reboot the system from the X-ray Console. If the
problem persists, contact your OLC.
Internal software
Messages count not found.
error
Reboot the system from the X-ray Console. If the
problem persists, contact your OLC.
Internal software
Messages number from the list not defined.
error
Reboot the system from the X-ray Console. If the
problem persists, contact your OLC.
Internal software
Message count not defined.
error
Reboot the system from the X-ray Console. If the
problem persists, contact your OLC.
ERR SUB A003 - Gantry Error Messages
Possible Cause/Recommended Action
Page no. 923
Senographe DS
Job Card
Chapter 9
- Quick Links:
- Err Sub A001 - Generator Error...
Hide quick links:
Advertisement
Table of Contents
Troubleshooting
Need help?
Do you have a question about the Senographe DS and is the answer not in the manual?
Questions and answers
G.E.Essential l have recently bought What is the full weight.of the mamo Full weight of the console and other İtem's also measurements of each item with the main machine please All this Shipping Company required
The GE Senographe DS mammography machine is shipped in three crates with the following dimensions and weights:
- Crate 1 (Gantry, Generator Cabinet, and ramp):
- Dimensions: 2066 mm (81.34 in) depth × 848 mm (33.39 in) width × 2292 mm (90.24 in) height
- Mass: 641 kg (1410.2 lbs)
- Crate 2 (Control Station):
- Dimensions: 1110 mm (43.70 in) depth × 770 mm (30.31 in) width × 1850 mm (72.83 in) height
- Mass: 210.5 kg (464.07 lbs) for truck transport (without side covers and lid)
- Mass: 223.5 kg (492.73 lbs) for plane/boat transport (with side covers and lid)
- Crate 3 (Detector):
- Dimensions: 872 mm (34.33 in) depth × 2270 mm (89.37 in) width × 260 mm (10.24 in) height
- Mass: 104.4 kg (229.68 lbs)
### Total Mass:
- For truck transport: 641 + 210.5 + 104.4 = 955.9 kg (2104.95 lbs)
- For plane/boat transport: 641 + 223.5 + 104.4 = 968.9 kg (2133.61 lbs)
These values include the gantry, generator cabinet, control station, detector, and all related components.
