GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Job Card ELE A008 - Configuring the 21-inch 3MP Monitor
7-2-2 Set the Monitor to Landscape Mode
By default, the 21-inch 3 MP Monitor is set to Potrait mode. Use the following steps to configure the 21-
inch 3 MP Monitor to use Landscape mode.
1. Ensure that the 21-inch 3 MP Monitor is powered OFF.
2. While pressing the Mode button, press the Power button to power on the 21-inch 3 MP Monitor.
The monitor powers up, and the Signal Selection window appears.
3. From the Signal Selection window select the Single Link/10bit item and press the Enter button.
4. From the Orientation window that appears, select the Landscape option and press the Enter button.
5. Double tap the Enter button to save the settings and close the Orientation window.
