GE Senographe DS Manual page 794

GE Healthcare
Revision 1
Job Card ELE A071 - Installation of CAD option on AWS
6-2 Declaration of the CAD option on the AWS
1. From the Browser, launch the Service Desktop (see
2. Access the CAD Home Page as follows:
• For V1/V2 Control Stations, from the Service Desktop, click the CAD button
• For V3/V4 Control Stations, from the Service Desktop, click the Utilities button
the Utilities page that appears, click the CAD icon to expand the CAD tree and then click the CAD
icon that is revealed.
The CAD Home page appears.
Note:
If existing CAD Units have already been declared, the CAD Home page lists the name, IP address,
and Hostname for each of the already declared CAD Units.
3. From the CAD Home Page, click the ADD button.
4. The bottom part of the CAD Home Page updates with the following three fields, allowing you to
declare the new CAD Unit:
• In the Label field, enter the name to be used to identify the CAD Unit in the Service desktop (e.g.
iCAD_SLDU). If the same CAD Unit is declared on more than one AWS, it is recommended that
the same name should be used on each AWS, to avoid confusion.
• In the IP address field, enter the IP address allocated to the CAD Unit.
• In the Hostname field, enter the hostname allocated to the CAD Unit (typically in the form
SLD#######, where ####### are the last seven digits of the CAD Unit serial number found on
the back of the computer). It may be necessary to insert the IP Address in the Host name field.
5. Click the SUBMIT button.
A message appears indicating that a ping to the CAD Unit is successful.
Note:
A message indicating that the DICOM Echo failed is also displayed. At this point, this is not an in-
dication of a problem.
If the declaration was not successful, check the network connections and try again.
6. After successful declaration, you can connect to the newly declared CAD Unit by selecting its radio
button and clicking the CONNECT TO button.
7. The newly declared CAD Unit must now be configured. Follow the instructions given in the CAD Unit
Service Manual to configure the newly declared CAD Unit.
Chapter 7
Service Information and Procedures Class A 2385072-16-8EN
Launching the Service Desktop on page
Page no. 794
Senographe DS
120).
.
. Then from
JC-ELE-A-071.fm
