ERR-SUB-A-003.fm
Service Information and Procedures Class A 2385072-16-8EN
Text in Log File or
on LCD
ROTATION ABSO-
LUTE ENCODER
ERROR
ROTATION MCU
CALIBRATION
DATA CORRUPT
ROTATION DSP
CALIBRATION
DATA CORRUPT
ROTATION MCU
EEPROM FAILURE
ROTATION POSI-
TION ERROR
Possible Cause/Recommended Action
The Rotation Potentiometer (absolute encoder) sig-
nal is too noisy. The change in the Rotation Poten-
tiomter voltage is significantly higher than expected
during normal motion for a period of at least 20 ms.
1. Check all cables are firmly connected on the
Rotation Board, and pass around the sides of the
Rotation Board. Ensure none of the cables pass
over the Rotation Board as this may lead to EMC
interference, and suprious error messages.
2. Ensure that the 6 mounting screws on the Rota-
tion Board are securely fastened so that the
Rotation Board is properly grounded.
3. Check the cabling and cable connection between
the Rotation Board and the Rotation Potentiome-
ter.
4. If the problem persists, the issue is not bad
cabling or bad earthing. Change the Rotation
Potentiometer then perform Rotation Calibration.
5. If the problem persists, change the Rotation
Board then perform Rotation Calibration.
The MCU calibration data is corrupt. The checksum
on the calibration data stored by the MCU does not
match.
Perform a rotation calibration. If the problem per-
sists, change the rotation board.
The DSP calibration data is corrupt. The checksum
on the calibration data stored by the DSP does not
match.
Perform a rotation calibration. If the problem per-
sists, check the rotation cabling, change the rotation
board.
There is an MCU EEPROM failure. The readback on
the newly written data to the EEPROM has failed.
Change the Rotation board then perform a Rotation
Calibration.
The rotation motion did not stop at the target/limit
position and went further than the allowed margin.
Refer to
JC DIAG A1115 ROTATION POSITION
OVERSHOOT/ROTATION CONTROL FAILURE on
page 954
to fix the problem.
Page no. 871
ERR SUB A003 - Gantry Error Messages
Senographe DS
Job Card
D/R A227
page
1239
D/R A221
page
1223
CAL A021
page
1679
CAL 021
page
1679
D/R A221
page
1223
CAL 021
page
1679
D/R A221
page
1223
D/R A221
page
1223
CAL 021
page
1679
A1115
page 954
Chapter 9
