Cable Lay-out and Pin-out
1-78. W411 - POS-Bus-2 Tilting Connect
Tilt Board PL401 J2 to Arm Distribution Board PL301 J9:
PIN (PL401)
PL401/J9-1
PL401/J9-2
PL401/J9-3
PL401/J9-4
PL401/J9-5
PL401/J9-6
PL401/J9-7
PL401/J9-8
PL401/J9-9
PL401/J9-10
PL401/J9-11
PL401/J9-12
1-79. W412 - HV Cable
Generator HV tank to X-ray tube J2.
1-80. W500 - Power/Lamp Control Cable
DC-DC Board PL402 J4 to Control Board PL403 J9:
Chapter 3
Service Information and Procedures Class A 2385072-16-8EN
Designation
H-CAN Network
L-CAN Network
GND
H-RT line 1
L-RT line 1
Stop motion
H-RT line 2
L-RT line 2
Reset line
GND
H-RT line 3
L-RT line 3
Designation
GND
Power_good_N
Power_good_P
Lamp_On
GND
24 V
Type
CAN Diff 5 / 2.5V
CAN Diff 2.5 / 0V
Ground
RT-CAN Diff 5 / 2.5 V
RT-CAN Diff 2.5 / 0V
RT
RT-CAN Diff 5 / 2.5 V
RT-CAN Diff 2.5 / 0V
RT
Ground
RT-CAN Diff 5 / 2.5 V
RT-CAN Diff 2.5 / 0V
Level
0 V
0 V
0/12 V
Open collector
0 V
24 V
Page no. 318
Level PIN (PL301)
PL301/J9-1
PL301/J9-2
0 V PL301/J9-3
PL301/J9-4
PL301/J9-5
0/+5 V PL301/J9-6
PL301/J9-7
PL301/J9-8
0/+5 V PL301/J9-9
0 V PL301/J9-10
PL301/J9-11
PL301/J9-12
Pin N°
J4-1
J4-2
J4-3
J4-4
J4-5
J4-6
