GE Senographe DS Manual page 843

GE Healthcare
Revision 1
Code Message text
078/005
078/128
079/001
079/002
079/003
079/004
079/005
079/006
079/008
079/009
079/010
079/011 E04 Arm fatal failure Exposure: no Gantry acknowledgment
079/013 E05 Failure Before
Exposure
079/014 E05 Failure during
exposure
ERR-SUB-A-001.fm
Service Information and Procedures Class A 2385072-16-8EN
Description
Gene init tests software error: defective
function will self-identify
Gene init tests software error: error fol-
lowing VRTX request
Exposure aborted: timeout
Exposure aborted: heater fault
Exposure aborted: anode starter fault
Exposure aborted: power fault
Exposure aborted: generator fault
Exposure: no Gantry acknowledgment
(at start of first trigger) or Gantry fault
Gantry fault detected before start of
exposure
Exposure: no sync signal from Gantry to
start exposure
Exposure aborted by mA meter (0 pt or
1 pt technique)
(at end of first trigger) or Gantry fault
Between AOP pre-exposure and AOP
exposure, the Generator sends a
StartSequence message to the IDC and
launches a timeout of 1200 ms. If the
Generator does not see the RT signal
XRAY_AUTHORIZE rising during this
timout, it generates error E05 079/013.
Probable cause:
1. Board or RT0 connector on IDC
aulty.
2. IDC-Generator RT/COM cable
(2244615) faulty.
3. Generator board issue/faulty.
Falling XRayAuthorizedRT signal not
received from IDC
Page no. 843
ERR SUB A001 - Generator Error Messages
Recommended actions
If the problem occurs during boot,
check optical fiber between Gantry
interface board and generator, also
can bus.
If the problem occurs when request-
ing an exposure, check the Bucky.
Check the error logs.
If there are any collimator reported
errors change the impacted collima-
tor-related FRUs.
If there are no collimator reported
errors change the other impacted sys-
tem-related FRUs.
From the Service Desktop, perform
the IDC DMR - RT Line diagnostics
using the loopback connectors from
the Loopback Kit.
If the problem persists, additionally try
adding DB9 Adaptors to the DB9
sockets on the IDC rear panel (see
Job Card TSG A012 - Use of DB9
Adaptors to Reduce Intermittent IDC
or ADS Communication Errors on
page 1029).
Switch the system off and on again;
repeat the exposure. Check the IDC-
Senographe communication
Senographe DS
Chapter 9
