GE Senographe DS Manual page 856

GE Healthcare
Revision 1
ERR SUB A003 - Gantry Error Messages
Code Category
102/002 HALT
102/04 HALT
102/005 HALT
102/006 HALT
102/007 HALT
102/008 HALT
102/009 HALT
102/010 HALT
102/012 HALT
Chapter 9
Service Information and Procedures Class A 2385072-16-8EN
Text in Log File or
on LCD
LIFT SPEED
ERROR
LIFT LOWSPEED
UNCONTROLLED
LIFT MOTION
LIFT FOOTSWITCH
DEFECT
LIFT FOOTSWITCH
DEFECT
COMPRESSION
FOOTSWITCH
DEFECT
COMPRESSION
FOOTSWITCH
DEFECT
LIFT OVER UPPER
LIMIT
LIFT OVER LOWER
LIMIT
Possible Cause/Recommended Action
When a coding wheel defect is detected through the
complemented hardware (HW) lines, the IPMS stops
and forbids the motion and sends an error message.
See JC DIAG A1005 LIFT CONTROL FAILURE on
page 946 to fix the problem.
The signal coming from motor encoder contains four
phases. A, A complementary, B, B complementary.
The Lift node checks two things: complementarity +
sequence of phases.
Check the lift operation in low speed and then refer
to JC DIAG A1013 LIFT CONTROL FAILURE on
page 948 to fix the problem.
There has been a Correlation Error. In case signals
from absolute coder (potentiometer) and coding
wheel (motor encoder) are not correlated.
Refer to JC DIAG A1008 LIFT CONTROL FAILURE
on page 947 to fix the problem.
SwitchDefect [i] (for i = 1 - 4) occurs when the two
signals from the button do not arrive at the same
time on the CPLD. [i] indicates the nature of the but-
ton and the side right or left. Double Footswitch con-
cerns 2 error signals and quadruple footswitches
concerns 4 error signals:
- Lift up
- Lift down
(- Compression up)
(- Compression down)
Refer to JC DIAG A1001 FOOTSWITCH IS
PRESSED on page 945
The IPMS detected that a motion has reached the
upper electrical stop limit. It stops and, forbids the
motion and sends an error message.
Refer to JC DIAG A1008 LIFT CONTROL FAILURE
on page 947 to fix the problem.
The IPMS detected that a motion has reached the
lower electrical stop limit. It stops, and forbids the
motion and sends an error message.
Refer to JC DIAG A1008 LIFT CONTROL FAILURE
on page 947 to fix the problem.
Page no. 856
to fix the problem.
Senographe DS
Job Card
A1005
page 946
A1013
page 948
A1008
page 947
A1001
page 945
A1008
page 947
A1008
page 947
