Cable Lay-out and Pin-out

This section lists Senographe system internal and external connecting cables.
1.

GANTRY CABLING

1-1. W001 - Earth Cable 1
MPCB box to Ground bar G301.
1-2. W002 - Earth Cable for EMC Filter E101
MPCB box to EMC filter E101.
1-3. W004 - Earth Cable for AC/DC Module Board PS101
MPCB box to AC/DC Module board PS101.
1-4. W005 - Earth Cable for AC/DC Converter Module
MPCB box to AC/DC Converter Module.
1-5. W006 - Earth Cable for Bulkhead Cover
MPCB box to bulkhead cover.
1-6. W101 - SYS-Bus 1 PDU Board to Interface Board
Connector: B20B-PHDSS 20 points - two in parallel
PDU Board PL101 J8 to Interface Board PL104 J2:
Cables.FM
Pin N°
J2-1
J2-2
J2-3
J2-4
J2-5 H-Expose Command
J2-6 L-Expose Command
J2-7
J2-8
J2-9
J2-10
J2-11
Service Information and Procedures Class A 2385072-16-8EN
Signal Name
H-Expose Enable
L-Expose Enable
Spare
0 Power Supply
Ground
P Reset
H-Xray On
L-Xray On
P Power On
Page no. 299
Senographe DS
Cable Lay-out and Pin-out
Signal description
RT-CAN Diff 5/2.5V
RT-CAN Diff 2.5/0V
Ground
RT-CAN Diff 5/2.5V
RT-CAN Diff 2.5/0V
Ground
Command RT 0/+5V
RT-CAN Diff 5/2.5V
RT-CAN Diff 2.5/0V
Command/reserved
