Job Card D/R A232 - Lift Screw Assembly

1 SUPPLIES
Determine the type of Lift Screw Assembly that is installed in the system, as indicated below.
TABLE 1 - LIFT SCREW ASSEMBLY TYPE IDENTIFICATION QUICK GUIDE
Manufacturing Date
Physical Identification Method
(required on Type 1 or Type 2 systems to
know if Lift Screw Assembly upgraded to
newer type)
L-bracket at top of Lift Screw Assembly
Motor power cable
Motor earth cable
Motor brake cable
Order the appropriate Lift Screw Assembly with Motor according to the Type of Lift Screw Assembly
installed in the system:
• For systems with Type 1 and Type 2, order a Type 2 Lift Screw Assembly with Motor (5191096)
• For systems with Type 3, order a Type 3 Lift Screw Assembly with Motor (5337148)
You may have determined with earlier troubleshooting that only the Lift Screw needs changing, rather
than the entire Lift Screw Assembly with Motor. In this case, order the appropriate Lift Screw according
to the Type of Lift Screw Assembly installed in the system:
• For systems with Type 1 and Type 2, order a Type 2 Lift Screw without Motor (5391083)
• For systems with Type 3, order a Type 3 Lift Screw without Motor (5373048)
2 TOOLS
• Standard Tool Box
screws located behind the Rotation board
• Gantry LOTO Tool
JC-DR-A-232.fm
pre-January 2008
threaded holes
including a universal joint (knuckle joint) for access to left hand side Cardan
Service Information and Procedures Class A 2385072-16-8EN
Lift Type in Install Base System
No brake
(Type 1)
Black with no Silver with threaded
YES
NO
NO
Page no. 1255
Job Card D/R A232 - Lift Screw Assembly
Top brake
(Type 2)
January 2008
holes
YES
YES
NO
Senographe DS
Chapter 9
Brake motor
(Type 3)
June 2011
Silver with no
threaded holes
YES
YES
YES
