Job Card DIAG A1000 - Gantry Diagnostic
FRUs:
2-33 JC DIAG A1215 COMPRESSION CONTROL FAILURE
Diagnostic for:
121/004 error code (CAN code is 0x9002) valid motion error
Error name: no valid line
Inspect the cables listed below. If you find any damage in a cable or connector, change it.
Check the cables in the following order:
- W213 - POS-BUS 1 cable for Lift to Rotation;
- W304A cable for paddle detector.
- W304B cable for paddle detector.
- W314 Sys Pos Bus cable.
- W311 - POS-BUS 2 cable for Bucky board;
If the error persists, change the Compression Board (see
page 1323).
If the error persists, change the Gantry CPU Board (see
page 1131).
FRUs:
2-34 JC DIAG A1216 COMPRESSION COMMUNICATION FAILURE
Diagnostic for:
122/040 error code (CAN code is 0x8210) invalid PDO length
• Change the Compression Board (see
• If the error persists, change the CPU Board (see
1131). If changing the CPU board solved the problem, put back the original Compression Board (see
Job Card D/R A250 - Compression Board on page
FRUs:
2-35 JC DIAG A1217 COMPRESSION CONTROL FAILURE
Diagnostic for:
122/021 error code
This error is reported when the value of the compression force is out of the -50% to +20% calibrated
Chapter 9
Service Information and Procedures Class A 2385072-16-8EN
Compression Board
Pot+cable
Compression Board
W314 Sys Pos Bus cable
W304A cable for paddle detector
W304B cable for paddle detector
W311 - POS-BUS 2 cable for Bucky board
W213 - POS-BUS 1 cable for Lift to Rotation
Nephtys Gantry CPU
Job Card D/R A250 - Compression Board on page
Compression Board
Nephtys Gantry CPU
(CAN code is 0x503D)
Job Card D/R A250 - Compression Board on
Job Card D/R A190 - Gantry CPU Board on
Job Card D/R A190 - Gantry CPU Board on page
1323).
force sensor range error
