ERR SUB A003 - Gantry Error Messages
Code Category
101/001 DEBUG
ONLY
101/002 DEBUG
ONLY
101/003 WARNING
101/004 WARNING
Chapter 9
Service Information and Procedures Class A 2385072-16-8EN
Text in Log File or
on LCD
LIFT SOFTWARE
ERROR
LIFT SOFTWARE
ERROR
LIFT CALIBRATION
ERROR
NO VALID LINE
FOR LIFT
Possible Cause/Recommended Action
On every command sent by the PTB, the IPMS
checks whether the command identifier is part of the
list of commands to be taken into account by IPMS. If
the command is not recognized, the command is
ignored, and "CommandIdError" is returned.
Should not occur in the field.
It could be a disconnect between the CPU soft
release and the Node soft release. Contact your
OLC if the problem persists.
On every command sent by the PTB, the IPMS
checks whether all parameters values are compati-
ble with their corresponding range. If not, the com-
mand is be ignored, and "ParameterError" is
returned to the PTB.
Should not occur in the field.
It could be a disconnect between the CPU soft
release and the Node soft release. Contact OLC if
the problem persists.
If the calibration is not achieved, for each CAN mes-
sage which is not a calibration command, the IPMS
ignores the command and sends the "CalibrationNot-
Achieved" error.
Use Job Card CAL A031 - Lift Calibration on page
1687 to perform a Lift calibration.
There is no valid line. The Gantry CPU requests a
motion but node does not see the valid line. The
valid line is an RT line, that is activated by the CPLD
of the node containing the UIF during the time when
the UIF is pressed + a deceleration time. This does
not concern decompression and tilt.
This also occurs when the valid line falls before the
end of the movement.
Valid line problem. check the different motions, using
all keypads to determinate the defective node then
refer to JC DIAG A1015 LIFT CONTROL FAILURE
on page 949.
