GE Healthcare
Revision 1
Job Card ELE A021 - Networking Connection and Configuration
20. At the Confirm Information screen that appears displaying the date and time settings, press the <F2>
key to continue.
Confirm Information
> Confirm the following information. If it is correct ...
.........................
Time zone:
Date and time: 2007-06-09 11:33
21. The Root Password screen appears prompting you to specify a root password for the Acquisition
Workstation.
Root Password
Please enter the root password for this system.
The root password may contain alphanumeric and special characters. For
security, the password will not be displayed on the screen as you type it.
> If you do not want a root password leave both entries blank.
Root password:
Root password:
Type the required root password (usually operator) in both the Root password fields and press the
<Return> key when done. The password you type is not displayed. The default password for root is
operator.
Note:
Ensure that the caps-lock key is not engaged before entering the password.
If there is a difference between the two entries, the system will request it again.
Press the <F2> key to continue.
22. When the configuration is complete, a System identification message appears.
System identification is completed.
The system then automatically reboots. Log in to the system according to
7-5
Login
•
The configuration process is now complete.
•
On completion of the boot sequence, the console login: prompt appears.
•
Login with the username sdc, and press the <Return> key at the password prompt, to restart the
system.
Chapter 7
Service Information and Procedures Class A 2385072-16-8EN
GMTn
Page no. 652
Senographe DS
Login on page
652.
JC-ELE-A-021.fm
