DS5
Figure of 8 LED used for error codes
DS6
DS7
DS8
DS9
Presence SECTeur
A status signal indicator from the
AC/DC 48 V power supply
DS10
A status signal indicator from the
AC/DC 48 V power supply
DS11
Over Temperature
DS12
DS13
Power ON/OFF
A control signal indicator from the PDU
to AC/DC 48 V power supply
DS14
48 V DC ON/OFF
Safety indicator
DS15
DS16
DS17
DS18
DS19
DS20
DS21
Indicators and Switches.fm
Power OK
Fan Fail
+ Input
+ 5 VD
+ 13 V
– Input
+ 5 VA
– 5 VA
+ 12 V System
Service Information and Procedures Class A 2385072-16-8EN
Red
When the system is functioning properly these
LEDs spell dEF. If the system has errors, these
LEDs display different error codes.
Default state:OFF
Not used.
Yellow ON when 48 V is not present at power supply output
or when the power is inhibited (i.e. bottom two pins
of jumper J22 are closed).
OFF when 48 V is present at power supply output
or when the power is not inhibited (i.e. the jumper
J22 is open).
Yellow ON when the PDU temperature is too high.
OFF when the PDU temperature is not too high.
Yellow ON when the fan on the PDU has failed.
OFF when the fan on the PDU has failed.
Yellow ON when the power is inhibited (i.e. bottom two pins
of jumper J22 are closed) or when PDU turns off the
48 V power.
OFF when the power is not inhibited (i.e. the jumper
J22 is open) or when PDU turns on the 48 V power.
Note: Normal operation is that power is not inhib-
ited (i.e. the jumper J22 is open) and the LED is
OFF.
Red
If DS13 is wrong or insertion is wrong, the behavior
is the same as DS13, otherwise:
ON when PDU turns off the 48 V power
OFF when PDU turns on the 48 V power
Green
ON when the + U supply voltage is OK
OFF when the + U supply voltage is defective
Green
ON when the 5 V logic supply voltage is OK
OFF when the 5 V logic supply voltage is defective
Green
ON when the 13 V supply voltage is OK
OFF when the 13 Vv supply voltage is defective
Green
ON when the – U supply voltage is OK
OFF when the – U supply voltage is defective
Green
ON when the +5 VA analog supply voltage is OK
OFF when the +5 VA analog supply voltage is
defective
Green
ON when the –5 VA analog supply voltage is OK
OFF when the –5 VA analog supply voltage is
defective
Green
ON when the 12 V system supply voltage is OK
OFF when the 12 V system supply voltage is defec-
tive
Page no. 291
