Code Category
100/004 WARNING
100/005 WARNING
100/006 WARNING
100/007 WARNING
100/009 HALT
100/010 HALT
100/011 WARNING
100/013 N/A
ERR-SUB-A-003.fm
Service Information and Procedures Class A 2385072-16-8EN
Text in Log File or
on LCD
FOOTSWITCH IS UIF Still Pressed [i] (for i =1 - 4) = Occurs when one
PRESSED of the 2 (resp 4) buttons on footswitches are pressed
during node boot-up:
FOOTSWITCH IS
- Lift up: 0x9006
PRESSED
- Lift down: 0x9005
FOOTSWITCH IS
(- Compression up): 0x9008
PRESSED
(- Compression down): 0x9007
FOOTSWITCH IS Right or left are not differentiated. Double Footswitch
PRESSED concerns 2 error signals and quadruple footswitches
concerns 4 error signals
See
on page 945
LIFT POSITION The Lift is over the upper software limit. Occurs
ERROR when the lift position is not between the software lim-
its at power-up (including a tolerance to be defined).
Typically, this can happen when the lift has been
moved manually.
Remove the Gantry covers; check the lift position. If
lift position locked into upper position, or close to the
upper position, move the lift down manually. To do
this, turn the lift screw to about 2 cm below the upper
optical fork.
LIFT POSITION The Lift is below the lower software limit. Occurs
ERROR when the lift position is not between the software lim-
its at power-up (including a tolerance to be defined).
Typically, this can happen when the lift has been
moved manually.
Remove the Gantry covers; check the lift position. If
the lift position locked into lower position, or close to
the lower position, move the lift up manually. To do
this, turn the lift screw to about 2 cm below the upper
optical fork.
GANTRY DISPLAY The LCD has failed.
FAILURE
Faulty FRU = LCD
Reboot the system from the X-ray Console. If the
problem persists, change the LCD.
RELAY DEFECT When the node moves to operational state it checks
if the relay state is according to the board safety
state (for example missing STOP_MOTION_LINE
has to disable the relay). This error is triggered,
when there are no safety problems on the board, but,
for some reason, the relay doesn't allow motion.
Probable root cause: Broken or stucked relay
The board shall be changed.
ERR SUB A003 - Gantry Error Messages
Possible Cause/Recommended Action
JC DIAG A1001 FOOTSWITCH IS PRESSED
to fix the problem.
