Job Card D/R A150 - System Fuses - GE Senographe DS Manual

GE Healthcare
Revision 1

Job Card D/R A150 - System Fuses

1 SUPPLIES
Fuses, according to the table below:
Sub-system location
Generator
(Conditioner cabinet
part)
Generator
Gantry
Note: If you are changing the F5 or F6 fuse on the PDU Board, do the following:
• If the PDU Board Part Number is 2365871-7 or below, order PDU Board 2365871-8 and change the entire PDU Board it according to
Job Card D/R A191 - PDU Board on page
• If the PDU Board Part Number is 2365871-8, order the fuse 5344386-2 and change it according to this Job Card.
JC-DR-A-150.fm
Service Information and Procedures Class A 2385072-16-8EN
Board/Location (illustration ref.)
Mains Distribution Assembly - F1 (illustration 1)
Mains Distribution Assembly - F2 (illustration 1)
Mains Distribution Assembly - F3 (illustration 1)
Mains Distribution Assembly - F4 (illustration 1)
Generator Command Board - F1 (illustration 2)
Generator Command Board - F2 (illustration 2)
Generator Command Board - F3 (illustration 2)
Supply Command Board - F1 (illustration 3)
Supply Command Board - F2 (illustration 3)
Supply Command Board - F3 (illustration 3)
Supply Command Board - F4 (illustration 3)
Supply Command Board - F5 (illustration 3)
Supply Command Board - F6 (illustration 3)
Next to circuit breaker - F1 (illustration 4)
Next to circuit breaker - F2 (illustration 4)
Mains Distribution Board - F1 (illustration 5)
Mains Distribution Board - F2 (illustration 5)
Mains Distribution Board - F3 (illustration 5)
PDU Board - F1 (illustration 6)
PDU Board - F3 (illustration 6)
PDU Board - F4 (illustration 6)
PDU Board - F5 (see note) (illustration 6)
PDU Board - F6 (see note) (illustration 6)
MPCB - F1 (illustration 6)
MPCB - F2 (illustration 6)
1137.
Page no. 1109
Job Card D/R A150 - System Fuses
Fuse Specification
250 Vac, 10 A, Delay
250 Vac, 5 A, Delay
250 Vac, 1.6 A, Delay
250 Vac, 5 A, Delay
250 Vac, 2.5 A, Delay
250 Vac, 2.5 A, Delay
250 Vac, 2.5 A, Delay
250 Vac, 3.15 A, Delay
250 Vac, 0.5 A, Delay
150 Vac, 125 A, Fast
380 Vac, 10 A, Fast
380 Vac, 10 A, Fast
250 Vac, 16 A, Fast
600 Vac, 35 A, Fast
600 Vac, 35 A, Fast
250 Vac, 1 A, Delay
250 Vac, 0.5 A, Delay
250 Vac, 0.5 A, Delay
250 Vac, 6.25 A, Delay
250 Vac, 0.5A, Delay
250 Vac, 2A, Delay
250 Vac, 125 mA, Delay
250 Vac, 125 mA, Delay
600 Vac, 20 A, Fast
600 Vac, 20 A, Fast
Senographe DS
Chapter 9
Fuse Part
Number
99183979
99183923
99183925
99183923
99194291
99194291
99194291
99194288
58079685
91684676
58079166
58079166
58079690
99184154
99184154
58079686
58079685
58079685
46-170021P60
46-170021P31
46-170021P30
5344386-2
5344386-2
2387747
2387747
