GE Senographe DS Manual page 894

GE Healthcare
Revision 1
ERR SUB A003 - Gantry Error Messages
Code Category
132/012 INHIBIT
132/013 INHIBIT
132/014 INHIBIT
132/015 INHIBIT
132/016 INHIBIT
132/017 INHIBIT
Chapter 9
Service Information and Procedures Class A 2385072-16-8EN
Text in Log File or
on LCD
Tube Tilt step lost
TILT NODE FW
INCOMPATIBILITY
TILT NODE PARITY
ERROR
LOW VOLTAGE
ERROR ON TILT
NODE
TILT READ TIME-
OUT ERROR
TILT CPLD MEM-
ORY ERROR
Possible Cause/Recommended Action
After the transition has been found, the Tube Tilt
goes up and down for a definite number of steps.
The Tube Tilt board checks that the transition is
reached after the good number of steps. If not, this
error signal is produced.
Refer to JC DIAG A1302 TUBE HEAD CONTROL
FAILURE on page 965
Tube Tilt Pivots on page 1397
Occurs when the hardware configuration (CPLD) of
the node or the DSP or the MCU firmware not match.
Change the Tilt board then perform a Tilt Calibration.
Occurs when the parity bit does not set correctly on
the on-board bus between the CPLD and the MCU.
Change the Tilt board then perform a Tilt Calibration.
Occurs if the voltage of the power supply to the Tube
Tilt board falls below 24 V.
Change the Tilt board then perform a Tilt Calibration.
Occurs if the MCU does not react within 15 ms of
receiving an interrupt request (IRQ) coming from the
CPLD.
Change the Tilt board then perform a Tilt Calibration.
Test data from the CPLD is periodically read to
ensure the proper communication. This error occurs
if this data from the CPLD does not match.
Change the Tilt board then perform a Tilt Calibration.
Page no. 894
and to Job Card D/R A292 -
to fix the problem.
Senographe DS
Job Card
A1302
page 965
D/R A292
page
1397
D/R A266
page
1365
CAL A027
page
1681
D/R A266
page
1365
CAL A027
page
1681
D/R A266
page
1365
CAL A027
page
1681
D/R A266
page
1365
CAL A027
page
1681
D/R A266
page
1365
CAL A027
page
1681
