GE Healthcare
Revision 1
Code
Message text
022/006
E10 Heating failure
track 1
022/007
E10 Heating failure
track 1
022/008
E10 Heating failure
track 1
023/001
E11 Heating failure
track 2
023/002
E11 Heating failure
track 2
023/003
E11 Heating failure
track 2
023/004
E11 Heating failure
track 2
023/005
E11 Heating failure
track 2
023/006
E11 Heating failure
track 2
023/007
E11 Heating failure
track 2
023/008
E11 Heating failure
track 2
027/003 E04 Arm fatal failure
027/004 E04 Arm fatal failure A Gantry error was signaled during the
ERR-SUB-A-001.fm
Service Information and Procedures Class A 2385072-16-8EN
Description
Heater track 1: mA value not significant
Heater track 1: signal Pres_Chauf
(Heater_Presence) goes 'low' after
exposure
Heater track 1: signal Pres_Chauf
(Heater_Presence) stays 'high' when
the heater stopped
Heater track 2: signal Pres_Chauf
(Heater_Presence) 'high' in standby
status
Heater track 2: signal Pres_Chauf
(Heater_Presence) stays 'low' when the
heater started
Heater track 2: signal Pres_Chauf
(Heater_Presence) goes 'low' during
pre-heater phase
Heater track 2: signal Pres_Chauf
(Heater_Presence) goes 'low' during
first trigger
Heater track 2: signal Pres_Chauf
(Heater_Presence) goes 'low' during
exposure
Heater track 2: mA value not significant
Heater track 2: signal Pres_Chauf
(Heater_Presence) 'low' after exposure
Heater track 2: signal Pres_Chauf
(Heater_Presence) stays 'high' when
the heater stopped
exposure. Occurs after an exposure
when the brightness has been received
and the Generator requests the Gantry
to put the grid into the home position. If
the Gantry does not answer within 3 sec
of the request, this error occurs.
Page no. 837
ERR SUB A001 - Generator Error Messages
Recommended actions
If the problem occurs during boot,
check optical fiber between Gantry
interface board and generator, also
can bus.
If the problem occurs when request-
ing an exposure, check the Bucky.
1. Reset Gantry and Generator (i.e.
press off/on on the X-ray Console).
2. Check other Gantry related errors
to determine the route cause. Proba-
ble route causes include the Bucky,
Collimator, and Filter Wheel.
Senographe DS
Chapter 9
