Revision 1
Step
Action
25
Repeat and Reject Analysis Configu-
ration
26
Installation of CAD Option onAWS
Hardware options
27
Install Required options
Mass Archiver - LaserCam - Review
Workstation
28
Install Bar Code Scanner if present
Refit covers
29
Refit Control Station Covers
Image Quality Checks
30
If Stereo or 2D Biopsy Optical Local-
izer option exists, calibrate the LCD
Monitor
31
Flat Field Check
32
Image Acquisition & ACR Score
33
Acquisition in AOP mode
Detector Dose check (Germany only)
34
Compliance with Germany for Detec-
tor Dose
Stereotaxy installation and configuration
35
If Stereotaxy Option is present
Completion
36
Complete AWS System configuration
form
37
Backup configuration information
38
Back-up/Restore procedure - Manual
record sheets
39
Clean up room and complete paper-
work
SC-ELE-A-001.fm
Service Information and Procedures Class A 2385072-16-8EN
Job Card
Job Card ELE A067 - Repeat and
Reject Analysis Configuration on page
791
Job Card ELE A071 - Installation of
CAD option on AWS on page 793
Job Card ELE A042 - Bar Code Scan-
ner (Option) on page 715
Job Card PHY A040 - Remove/Reinstall
Control Station Covers on page 503
Job Card ELE A043 - AWS Monitor Cal-
ibration on page 729
Job Card ELE A032 – IQ Tools Flat
Field Test on page 699
Job Card ELE A037 - Image Acquisition
and ACR Score on page 705
Job Card ELE A038 - AOP Mode and
SNR Check on page 707
Job Card ELE A039 - Compliance with
Germany for Detector Dose on page
711
Refer to Stereotaxy SM (2390552)
Form LBK A001 - System Configuration
Form on page 797
Job Card ELE A052 - Back-up/Restore
Procedure on page 771
Form LBK A003 - Back-up/Restore Pro-
cedure - AWS Parameters Manual
Record Sheets on page 801
Page no. 539
Scenario ELE A001 - Electrical Installation
Comments
Refer to supplied
manuals
Germany
Senographe DS
Done
Only in
Chapter 7
