GE Senographe DS Manual page 883

GE Healthcare
Revision 1
Code Category
122/009 HALT
122/010 HALT
122/011 HALT
122/012 HALT
122/013 HALT
122/014 HALT
122/015 HALT
122/016 HALT
122/017 HALT
122/018 HALT
122/019 HALT
122/020 HALT
ERR-SUB-A-003.fm
Service Information and Procedures Class A 2385072-16-8EN
Text in Log File or
on LCD
LIFT UP BUTTON
STILL PRESSED
LIFT UP BUTTON
STILL PRESSED
LIFT DOWN BUT-
TON STILL
PRESSED
LIFT DOWN BUT-
TON STILL
PRESSED
ROTATION BUT-
TON STILL
PRESSED
ROTATION BUT-
TON STILL
PRESSED
ROTATION BUT-
TON STILL
PRESSED
ROTATION BUT-
TON STILL
PRESSED
CC BUTTON STILL
PRESSED
+MLO BUTTON
STILL PRESSED
-MLO BUTTON
STILL PRESSED
COMPR BRAKES
LOW CURRENT
Possible Cause/Recommended Action
SwitchDefect [i] (for i = 1 - 11) occurs when the two
signals from the button do not arrive at the same
time on the CPLD.
The error signal indicates the nature of the button but
not the side right or left.
- Lift up (V1, V2)
- Lift down (V1, V2)
- Rotation Right (V1, V2)
- Rotation Left (V1, V2)
- Preset CC
- Preset +MLO
- Preset -MLO
See JC DIAG A1201 KEYPAD FAILURE on page
956 to fix the problem.
There is low brake current. Screwbrake brakes when
no current in it. Manual compression brake brakes
when supplied with current. The two brakes are sup-
plied from the same point and one of them brakes at
least all the time. In case the current that goes to the
two brakes falls below an acceptable limit, this signal
is sent.
See JC DIAG A1212 COMPRESSION BRAKE FAIL-
URE on page 960 to fix the problem.
Page no. 883
ERR SUB A003 - Gantry Error Messages
Senographe DS
Job Card
A1201
page 956
A1212
page 960
Chapter 9
