GE Healthcare
Revision 1
Code
Category
141/016
INHIBIT
141/017
INHIBIT
141/018
INHIBIT
141/019
INHIBIT
141/020
INHIBIT
ERR-SUB-A-003.fm
Text in Log File or
on LCD
Coll front blade time-
out
Coll left blade time-
out
Coll rear blade time-
out
Coll right blade time-
out
Coll filter timeout
Service Information and Procedures Class A 2385072-16-8EN
Possible Cause/Recommended Action
Axis[i] (for i=1 - 5) time out = axis[i] does not reach
target position within timeout limit.
Possible reasons:
1. Cables (drive cable or motor cable) are loose or
broken.
2. Control board failure.
3. Overcurrent during the movement.
Actions to correct problem:
1. Check into the error log if other error message
occurs together with the Collimator timeout error.
- If yes, replace the Collimator Set (refer to
Card D/R A280 - Collimator Set on page
- If not, check the motor drive cable (W501) and
then restart the system.
2. If the error still exists, replace the Collimator Set
(refer to
Job Card D/R A280 - Collimator Set on
page
1369).
3. Perform Collimator Format Calibration.
axis[i] (for i=1 - 5) time out = axis[i] does not reach
target position within timeout limit.
Possible reasons:
1. Cables (drive cable or motor cable) are loose or
broken.
2. Control board failure.
3. Overcurrent during the movement.
Actions to correct problem:
1. Move the filter wheel manually. Check whether
there is mechanical interference with tube tilt
plate screw. If there is mechanical interference
with tube tilt plate screw, it may be linked to tube
tilt plate assembly problem.
2. If not, check whether there is mechanical inter-
ference between the filter wheel flag and the
small filter gear.
3. If there is mechanical interference between the
filter wheel flag and the small filter gear, change
the Collimator set. Refer to
Collimator Set on page
4. If not, refer to the actions for the Blade Timeout
error.
Page no. 903
ERR SUB A003 - Gantry Error Messages
1369).
Job Card D/R A280 -
1369.
Senographe DS
Job Card
D/R A280
page
Job
1369
CAL A029
page
1683
D/R A280
page
1369
CAL A029
page
1683
Chapter 9
- Quick Links:
- Err Sub A001 - Generator Error...
Hide quick links:
Advertisement
Table of Contents
Troubleshooting
Need help?
Do you have a question about the Senographe DS and is the answer not in the manual?
Questions and answers
G.E.Essential l have recently bought What is the full weight.of the mamo Full weight of the console and other İtem's also measurements of each item with the main machine please All this Shipping Company required
The GE Senographe DS mammography machine is shipped in three crates with the following dimensions and weights:
- Crate 1 (Gantry, Generator Cabinet, and ramp):
- Dimensions: 2066 mm (81.34 in) depth × 848 mm (33.39 in) width × 2292 mm (90.24 in) height
- Mass: 641 kg (1410.2 lbs)
- Crate 2 (Control Station):
- Dimensions: 1110 mm (43.70 in) depth × 770 mm (30.31 in) width × 1850 mm (72.83 in) height
- Mass: 210.5 kg (464.07 lbs) for truck transport (without side covers and lid)
- Mass: 223.5 kg (492.73 lbs) for plane/boat transport (with side covers and lid)
- Crate 3 (Detector):
- Dimensions: 872 mm (34.33 in) depth × 2270 mm (89.37 in) width × 260 mm (10.24 in) height
- Mass: 104.4 kg (229.68 lbs)
### Total Mass:
- For truck transport: 641 + 210.5 + 104.4 = 955.9 kg (2104.95 lbs)
- For plane/boat transport: 641 + 223.5 + 104.4 = 968.9 kg (2133.61 lbs)
These values include the gantry, generator cabinet, control station, detector, and all related components.
