GE Healthcare
Revision 1
Code
Category
161/023 ADVISORY
161/024 ADVISORY
161/025 ADVISORY
161/026 ADVISORY
161/027 ADVISORY
161/028 ADVISORY
161/030
HALT
161/031
HALT
ERR-SUB-A-003.fm
Text in Log File or
on LCD
LCD: A06 Lift end
position is reached
LCD: A05 Compres-
sion upper position is
reached
LCD: A09 Max
power driven com-
pression force is
reached
LCD: A08 Max man-
ual compression
force is reached
LCD: A14 Risk of
collision with floor
LCD: A14 Risk of
collision with floor
COMPRESSION
CONTROL FAILURE
LIFT CONTROL
FAILURE
Service Information and Procedures Class A 2385072-16-8EN
Possible Cause/Recommended Action
The lift UIF request was rejected by the Gantry CPU
because it is already at its end position.
Operator error. No service recommended actions.
The compression UIF request was rejected by the
Gantry CPU because it is already in its topmost posi-
tion.
Operator error. No service recommended actions.
The maximum power-driven compression force has
been reached.
Operator error. No service recommended actions.
The maximum manual compression force has been
reached.
Operator error. No service recommended actions.
An active lift motion was stopped or a lift UIF request
was rejected because a potential collision situation
was detected by the Gantry CPU.
Operator error. No service recommended actions.
A rotation lift motion was stopped or a rotation UIF
request was rejected because a potential collision
situation was detected by the Gantry CPU.
Operator error. No service recommended actions.
The compression node did not start. At power-up,
the compression node sends an acknowledgment
(which can be different from the first heartbeat sig-
nal) to Gantry CPU. If the compression node does
not send an acknowledgment, the Gantry CPU cre-
ates this error.
Reboot the system from the X-ray Console. If the
problem persists, contact your OLC.
The lift node did not start. At power-up, the lift node
sends an acknowledgment (which can be different
from the first heartbeat signal) to Gantry CPU. If the
lift node does not send an acknowledgment, the
Gantry CPU creates this error.
Reboot the system from the X-ray Console. If the
problem persists, contact your OLC.
Page no. 913
ERR SUB A003 - Gantry Error Messages
Senographe DS
Job Card
Chapter 9
- Quick Links:
- Err Sub A001 - Generator Error...
Hide quick links:
Advertisement
Table of Contents
Troubleshooting
Need help?
Do you have a question about the Senographe DS and is the answer not in the manual?
Questions and answers
G.E.Essential l have recently bought What is the full weight.of the mamo Full weight of the console and other İtem's also measurements of each item with the main machine please All this Shipping Company required
The GE Senographe DS mammography machine is shipped in three crates with the following dimensions and weights:
- Crate 1 (Gantry, Generator Cabinet, and ramp):
- Dimensions: 2066 mm (81.34 in) depth × 848 mm (33.39 in) width × 2292 mm (90.24 in) height
- Mass: 641 kg (1410.2 lbs)
- Crate 2 (Control Station):
- Dimensions: 1110 mm (43.70 in) depth × 770 mm (30.31 in) width × 1850 mm (72.83 in) height
- Mass: 210.5 kg (464.07 lbs) for truck transport (without side covers and lid)
- Mass: 223.5 kg (492.73 lbs) for plane/boat transport (with side covers and lid)
- Crate 3 (Detector):
- Dimensions: 872 mm (34.33 in) depth × 2270 mm (89.37 in) width × 260 mm (10.24 in) height
- Mass: 104.4 kg (229.68 lbs)
### Total Mass:
- For truck transport: 641 + 210.5 + 104.4 = 955.9 kg (2104.95 lbs)
- For plane/boat transport: 641 + 223.5 + 104.4 = 968.9 kg (2133.61 lbs)
These values include the gantry, generator cabinet, control station, detector, and all related components.
