ERR SUB A001 - Generator Error Messages
Code Message text
094/003 E18 IDC/Seno syn-
chro failure.
094/004 E18 IDC/Seno syn-
chro failure.
094/005 E18 IDC/Seno syn-
chro failure.
094/006 E18 IDC/Seno syn-
chro failure.
094/007 E18 IDC/Seno syn-
chro failure.
096/019 I34 Thickness out of
AOP range
096/020 I36 IFF threshold
out of range
096/021 I37 9 param model
deviate
096/023 I05 Exposure
aborted by mAs
level
Chapter 9
Service Information and Procedures Class A 2385072-16-8EN
Description
An error occurs on IDC or on
Senographe which generates an error
on a signal/message expected from the
IDC task of the Senographe: Stop com-
mand at end of exposure not received
by the IDC task.
An error occurs on IDC or on
Senographe which generates an error
on a signal/message expected from the
IDC task of the Senographe: XRayAu-
thorizedRT status not received by the
IDC task.
An error occurs on IDC or on
Senographe which generates an error
on a signal/message expected from the
IDC task of the Senographe: Stop com-
mand not received by the IDC task at
the end of the Radiography.
An error occurs on IDC or on
Senographe which generates an error
on a signal/message expected from the
IDC task of the Senographe: Prep com-
mand not received by the exposure
automaton (task T_APPLI)
An error occurs on IDC or on
Senographe which generates an error
on a signal/message expected from the
IDC task of the Senographe: XRayAu-
thorizedRT signal active in idle status
Thickness out of AOP range.
IFF (IDC algorithm) threshold out of
range.
Error on Scf factor for the pre-exposure Warning given in AOP mode between
mAs value performed for the pre-expo-
sure out of range
Page no. 848
Senographe DS
Recommended actions
Check communication between IDC
and Senographe, perform comm
diagnostics, perform IDC diagnostics
Check communication between IDC
and Senographe, perform comm
diagnostics, perform IDC diagnostics
Check communication between IDC
and Senographe, perform comm
diagnostics, perform IDC diagnostics
Check communication between IDC
and Senographe, perform comm
diagnostics, perform IDC diagnostics.
If the problem persists, additionally try
adding DB9 Adaptors to the DB9
sockets on the IDC rear panel (see
Job Card TSG A012 - Use of DB9
Adaptors to Reduce Intermittent IDC
or ADS Communication Errors on
page 1029).
Check communication between IDC
and Senographe, perform comm
diagnostics, perform IDC diagnostics
None (warning only)
None (warning only)
pre-exp. and exposure, if the cor-
rected mechanical thickness is equal
to 0 or breast composition is out of the
range 0.6 to 1.4. Check consistency
between radiological and mechanical
thickness after pre-exposure. Check
gene. display.
Reboot the full system.
